Technical specifications of the agricultural tractors John Deere 5080G, 5090G:
John Deere 5080G
- Years of production: 2009-13
- Maximum engine power (HP) / at RPM: 74/2200
- Number of gearbox speeds (forward + reverse): 24+24 (12+12)
- Maximum speed (km/h): 40 (30)
- Fuel tank capacity (L): 96
John Deere 5090G
- Years of production: 2009-13
- Maximum engine power (HP) / at RPM: 84/2200
- Number of gearbox speeds (forward + reverse): 24+24 (12+12)
- Maximum speed (km/h): 40 (30)
- Fuel tank capacity (L): 96
For details and a comparison of the tractors, see the technical sheet below.
Advertisement
Technical Data Sheet for John Deere 5080G and 5090G tractors:
| Model | John Deere 5080G | John Deere 5090G |
|---|---|---|
| Years of production | 2009-13 | 2009-13 |
| Engine designation/type | – | – |
| Number of cylinders / Turbo / Intercooler | 4TI | 4TI |
| Engine displacement (cm³) | 4530 | 4530 |
| Piston diameter / Stroke (mm) | 106,5×127 | 106,5×127 |
| Maximum engine power (HP) / at RPM | 74/2200 | 84/2200 |
| Torque (Nm) / at RPM | 325/1600 | 365/1600 |
| Number of gearbox speeds (forward + reverse) | 24+24 (12+12) | 24+24 (12+12) |
| Number of synchronized gears (forward + reverse) | 24+24 (12+12) | 24+24 (12+12) |
Advertisement
| Fast gearbox / Power shift | – | – |
|---|---|---|
| Reverser type | hydr | hydr |
| Speed range (km/h) | 0,5-40 | 0,5-40 |
| Maximum speed (km/h) | 40 (30) | 40 (30) |
| Hydraulic pump capacity (L/min) | 47 (60) | 47 (60) |
| Rear three-point hitch (TUV) control type | mech | mech |
| Maximum rear three-point hitch (TUV) lift capacity (kg) | 2600 | 2600 |
| Power take-off (PTO) speed (RPM) | 540/750 | 540/750 |
| Type of disc brake (dry/wet) | – | – |
| Brake system control type | – | – |
| Turning radius 2WD (m) | – | – |
| Turning radius 4WD (m) | – | – |
Advertisement
| Front tire size 2WD | – | – |
|---|---|---|
| Front tire size 4WD | 11.2R24 | 11.2R24 |
| Rear tire size 2WD | – | – |
| Rear tire size 4WD | 16.9R30 | 16.9R30 |
| Total weight 2WD (kg) | – | – |
| Total weight 4WD (kg) | 3215 | 3215 |
| Total height with cabin (cm) | 236 | 236 |
| Total length (cm) | 385 | 385 |
| Total width (cm) | 219/218 | 219/218 |
| Fuel tank capacity (L) | 96 | 96 |
| Cabin noise level (dB) | 81 | 81 |
