Lamborghini Crono 554-50, 564-60, 574-70 ⚙️ Specs

Technical Specifications of the Lamborghini Crono 554-50 Agricultural Tractor:

The Lamborghini Crono 554-50 Agricultural Tractor features a three-cylinder engine, model 1000.3A3, with a displacement of 3000 cm³. It delivers a maximum output of 50 HP at 2350 rpm and a torque of 172 Nm at 1600 rpm. The transmission offers 16 forward and 8 reverse gears, fully synchronized, with a mechanical high-speed gearbox. Travel speed ranges from 1.5 to 40.0 km/h. The hydraulic pump has a flow rate of 33 or 45 L/min, and the mechanical rear lift has a maximum lifting capacity of 2960 kg. The PTO operates at speeds of 540 and 750 rpm. The turning radius is 6.8 m in the 2WD version and 6.9 m in the 4WD version. The 2WD tire sizes are 7.50-16 in the front and 14.9R28 in the rear, while the 4WD sizes are 11.2R20 and 14.9R28. The tractor’s dimensions range from 338-348 cm in length, 193-198 cm in width, and 224 cm in height, with a weight of 2090 kg in the 2WD version and 2310 kg in the 4WD version. The fuel tank capacity is 58 liters, and the noise level inside the cabin is 85 dB.

Advertisement

Technical Data Sheet for Lamborghini Crono 554-50, 564-60, 574-70 Tractors:

Model Lamborghini Crono 554-50 Lamborghini Crono 564-60 Lamborghini Crono 574-70
Years of production
Engine model / type 1000.3A3 1000.3A4 1000.3AT
Number of cylinders / turbocharging 3 3 3T
Engine displacement (cm3) 3000 3000 3000
Piston dimension / stroke (mm) 105×115,5 105×115,5 105×115,5
Maximum engine power (hp) / rpm 50/2350 60/2350 70/2350
Torque (Nm) / rpm 172/1600 201/1500 255/1450
Number of gears (front + rear) 16+8 16+8 16+8
Number of synchronized gears (front+rear) 16+8 16+8 16+8

Advertisement

Speed-Shift mech mech mech
Type of reverse
Driving speed (km/h) 1,5-40,0 1,5-40,0 1,5-40,0
Max Driving speed (km/h)
Hydraulic pump capacity (L/min) 33/45 33/45 33/45
3-Point Hitch control mech mech mech
3-point hitch max load (kg) 2960 2960 2960
PTO speed (rpm) 540/750 540/750 540/750
Disc brake type (dry / wet)
Type of control of the braking system hydr hydr hydr
Turning radius 2WD (m) 6,8 7,1 7,1
Turning radius 4WD (m) 6,9 7,2 7,2

Advertisement

Front wheel 2WD 7,50-16 7,50-16 7,50-18
Front wheel 4WD 11,2R20 9,5R24 11,2R24
Rear wheel 2WD 14,9R28 14,9R30 16,9R30
Rear wheel 4WD 14,9R28 14,9R30 16,9R30
2WD total weight (kg) 2090 2260 2360
4WD total weight (kg) 2310 2500 2600
Total height with cabin (cm) 224 234 238
Total length (cm) 338/348 359/374 359/374
Total width (cm) 198/193 211/206 211/206
Fuel tank capacity (l) 58 58 58
Cabin sound level (dB) 85 84 85
