Technical specifications of the agricultural tractor Lamborghini Dorado 56/66/76/86:
Advertisement
| Model | Lamborghini Dorado 56 | Lamborghini Dorado 66 | Lamborghini Dorado 76 | Lamborghini Dorado 86 |
| Years of production | – | – | – | – |
| Engine model / type | 1000.3 W | 1000.3 WT | 1000.4 W | 1000.4 WT |
| Number of cylinders / turbocharging | 3 | 3T | 4 | 4T |
| Engine displacement (cm3) | 3000 | 3000 | 4000 | 4000 |
| Piston dimension / stroke (mm) | 105×115,5 | 105×115,5 | 105×115,5 | 105×115,5 |
| Maximum engine power (hp) / rpm | 52/2200 | 67/2200 | 70/2200 | 83/2200 |
| Torque (Nm) / rpm | 205/1400 | 260/1400 | 257/1400 | 348/1400 |
| Number of gears (front + rear) | 30+15/45+45 | 30+15/45+45 | 30+15/45+45 | 30+15/45+45 |
| Number of synchronized gears (front+rear) | 30+15/45+45 | 30+15/45+45 | 30+15/45+45 | 30+15/45+45 |
Advertisement
| Speed-Shift | – | – | – | – |
| Type of reverse | – | – | – | – |
| Driving speed (km/h) | 0,2-40 | 0,2-40 | 0,2-40 | 0,2-40 |
| Max Driving speed (km/h) | – | – | – | – |
| Hydraulic pump capacity (L/min) | 54 | 54 | 54 | 54 |
| 3-Point Hitch control | mech | mech | mech | mech |
| 3-point hitch max load (kg) | 3600 | 3600 | 3600 | 3600 |
| PTO speed (rpm) | 540/750 | 540/750 | 540/750/1000 | 540/750/1000 |
| Disc brake type (dry / wet) | – | – | – | – |
| Type of control of the braking system | – | – | – | – |
| Turning radius 2WD (m) | 6,12 | 6,4 | 6,4 | – |
| Turning radius 4WD (m) | 7,3 | 7,3 | 7,6 | 7,6 |
Advertisement
| Front wheel 2WD | 7.50-16 | 7.50-18 | 7.50-18 | – |
| Front wheel 4WD | 11.2R24 | 11.2R24 | 320/70R24 | 320/70R24 |
| Rear wheel 2WD | 12.4R36 | 480/70R30 | 480/70R30 | |
| Rear wheel 4WD | 12.4R36 | 12.4R36 | 480/70R30 | 480/70R30 |
| 2WD total weight (kg) | 2600 | 2700 | 2750 | – |
| 4WD total weight (kg) | 2750 | 2800 | 2900 | 2950 |
| Total height with cabin (cm) | 240 | 240 | 244 | 244 |
| Total length (cm) | 361 | 361 | 374 | 374 |
| Total width (cm) | 206 | 212/206 | 224/219 | 224/219 |
| Fuel tank capacity (l) | 90 | 90 | 90 | 90 |
| Cabin sound level (dB) | 76 | 76 | 76 | 76 |
