Lamborghini R4.85, R4.95, R4.105 ⚙️ Specs

Technical Specifications of the Lamborghini R4.85 Agricultural Tractor:

The Lamborghini R4.85 Agricultural Tractor features a four-cylinder turbocharged engine, model 1000.4-WT, with a displacement of 4000 cm³. It delivers a maximum output of 85 HP at 2300 rpm and a torque of 344 Nm at 1400 rpm. The transmission is available in 20+20 or 60+60 synchronized configurations, with a mechanical or hydraulic power shuttle. Travel speed ranges from 0.5 to 37.8 km/h, with a top speed of 40 km/h. The hydraulic pump has a flow rate of 58 L/min, and the electronically controlled rear lift (EHR) offers a maximum lifting capacity of 4800 kg, with an optional upgrade to 6200 kg. The PTO operates at speeds of 540 and 750 rpm. The turning radius is 7.2 m in the 2WD version and 9.3 m in the 4WD version. The 2WD tire sizes are 10.00-16 in the front and 16.9R34 in the rear, while the 4WD sizes are 13.6R24 and 16.9R34. The tractor’s dimensions include a length of 410 cm, a width of 238 cm, and a height of 280 cm, with a weight of 3630 kg in the 2WD version and 4055 kg in the 4WD version. The fuel tank capacity is 150 liters, and the noise level inside the cabin is 75 dB.

Advertisement

Technical Data Sheet for Lamborghini R4.85, R4.95, R4.105 Tractors:

Model Lamborghini R4.85 Lamborghini R4.95 Lamborghini R4.105
Years of production
Engine model / type 1000.4-WT 1000.4-WT 1000.6W
Number of cylinders / turbocharging 4T 4T 6
Engine displacement (cm3) 4000 4000 6000
Piston dimension / stroke (mm) 105×115,5 105×115,5 105×115,5
Maximum engine power (hp) / rpm 85/2300 91/2300 100/2300
Torque (Nm) / rpm 344/1400 367/1400 391/1400
Number of gears (front + rear) 20+20/60+60 20+20/60+60 20+20/60+60
Number of synchronized gears (front+rear) 20+20/60+60 20+20/60+60 20+20/60+60

Advertisement

Speed-Shift
Type of reverse mech/hydr mech/hydr mech/hydr
Driving speed (km/h) 0,5-37,8 0,5-37,8 0,5-37,8
Max Driving speed (km/h) 40 40 40
Hydraulic pump capacity (L/min) 58 58 58
3-Point Hitch control ehr ehr ehr
3-point hitch max load (kg) 4800 (6200) 4800 (6200) 4800 (6200)
PTO speed (rpm) 540/750/ 540/750/ 540/750/
Disc brake type (dry / wet)
Type of control of the braking system
Turning radius 2WD (m) 7,2
Turning radius 4WD (m) 9,3 9,3 9,86

Advertisement

Front wheel 2WD 10.00-16
Front wheel 4WD 13.6R24 13.6R24 14.9R24
Rear wheel 2WD 16.9R34
Rear wheel 4WD 16.9R34 16.9R34 520/70R34
2WD total weight (kg) 3630
4WD total weight (kg) 4055 4055 4320
Total height with cabin (cm) 280 280 283
Total length (cm) 410 410 445
Total width (cm) 238 247/238 264
Fuel tank capacity (l) 150 150 175
Cabin sound level (dB) 75 75 75
