Massey Ferguson 3630

Massey Ferguson 3630, 3640, 3650 – specs, opinions & photos

Looking for information about agricultural tractors Massey Ferguson 3630, 3640, 3650? In this article, you'll find answers to questions such as:

  • How much horsepower does each model have?
  • What is the engine capacity of these models?
  • What is the hydraulic pump output for each one?
  • What is the PTO speed of these tractors?

With a spec sheet presented in table form, comparing the tractors is quick and easy, and user reviews will help you make the right choice.

Table of contents:

Technical specifications of the agricultural tractors Massey Ferguson 3630, 3640, 3650:

Massey Ferguson 3630
Massey Ferguson 3640
Massey Ferguson 3650

Massey Ferguson 3630

  • Years of production: 2013-
  • Maximum engine power (HP) / at RPM: 76/2200
  • Number of gearbox speeds (forward + reverse): 24+24/24+12
  • Maximum speed (km/h): 40
  • Fuel tank capacity (L): 110

Massey Ferguson 3640

  • Years of production: 2013-
  • Maximum engine power (HP) / at RPM: 84/2200
  • Number of gearbox speeds (forward + reverse): 24+24/24+12
  • Maximum speed (km/h): 40
  • Fuel tank capacity (L): 110

Massey Ferguson 3650

  • Years of production: 2013-
  • Maximum engine power (HP) / at RPM: 84/2200
  • Number of gearbox speeds (forward + reverse): 24+24/24+12
  • Maximum speed (km/h): 40
  • Fuel tank capacity (L): 110

For details and a comparison of the tractors, see the technical sheet below.

Advertisement


Technical Data Sheet for Massey Ferguson 3630, 3640, 3650 Farm tractors:

Comparison of technical parameters of agricultural tractors
Model Massey Ferguson 3630 Massey Ferguson 3640 Massey Ferguson 3650
Years of production 2013- 2013- 2013-
Engine designation/type 33CTA 33CTA 33CTA
Number of cylinders / Turbo / Intercooler 3TI 3TI 3TI
Engine displacement (cm³) 3300 3300 3300
Piston diameter / Stroke (mm) 108×120 108×120 108×120
Maximum engine power (HP) / at RPM 76/2200 84/2200 84/2200
Torque (Nm) / at RPM 315/1400 345/1400 345/1400
Number of gearbox speeds (forward + reverse) 24+24/24+12 24+24/24+12 24+24/24+12
Number of synchronized gears (forward + reverse) 24+24/24+12 24+24/24+12 24+24/24+12

See also: Catalog of filters for Massey Ferguson tractors

Advertisement

Fast gearbox / Power shift mech/hydr mech/hydr mech/hydr
Reverser type mech/hydr mech/hydr mech/hydr
Speed range (km/h) 0,5-40 0,5-40 0,5-40
Maximum speed (km/h) 40 40 40
Hydraulic pump capacity (L/min) 48 (62) 62 62
Rear three-point hitch (TUV) control type mech mech mech
Maximum rear three-point hitch (TUV) lift capacity (kg) 2500 2500 2500 (3000)
Power take-off (PTO) speed (RPM) 540/750 540/750 540/750
Type of disc brake (dry/wet) – – –
Brake system control type – – –
Turning radius 2WD (m) – – –
Turning radius 4WD (m) 7 7 7

Advertisement

Front tire size 2WD 7.50-16 7.50-16 7.50-16
Front tire size 4WD 11.2R24 11.2R24 11.2R24
Rear tire size 2WD 16.9R30 16.9R30 16.9R30
Rear tire size 4WD 16.9R30 16.9R30 16.9R30
Total weight 2WD (kg) 3140 3140 3140
Total weight 4WD (kg) 3260 3260 3260
Total height with cabin (cm) 251 251 251
Total length (cm) 374 374 374
Total width (cm) 208 208 208
Fuel tank capacity (L) 110 110 110
Cabin noise level (dB) 80 80 80
