Technical specifications of the agricultural tractor New Holland TN60DA/TN70DA/TN75DA/TN85DA/TN95DA:
Advertisement
| Model | New Holland TN60DA | New Holland TN70DA | New Holland TN75DA | New Holland TN85DA | New Holland TN95DA |
| Years of production | – | – | – | – | – |
| Engine model / type | 8035.05 | 8035.45 | 8035.25 | NEF | NEF |
| Number of cylinders / turbocharging | 3 | 3T | 3T | 4 | 4T |
| Engine displacement (cm3) | 2930 | 2930 | 2930 | 4485 | 4485 |
| Piston dimension / stroke (mm) | 104×115 | 104×115 | 104×115 | 104×132 | 104×132 |
| Maximum engine power (hp) / rpm | 59/2300 | 72/2300 | 76/2300 | 82/2300 | 90/2300 |
| Torque (Nm) / rpm | 215/1400 | 282/1400 | 296/1400 | 320/1400 | 365/1400 |
| Number of gears (front + rear) | 16+16 | 16+16 | 16+16 | 16+16 | 12+12 |
| Number of synchronized gears (front+rear) | 16+16 | 16+16 | 16+16 | 16+16 | 12+12 |
Advertisement
| Speed-Shift | – | – | – | – | – |
| Type of reverse | mech/hydr | mech/hydr | mech/hydr | mech/hydr | mech/hydr |
| Driving speed (km/h) | 0,8-39,2 | 0,8-39,2 | 0,8-39,2 | 0,8-39,2 | 0,8-39,2 |
| Max Driving speed (km/h) | – | – | – | – | – |
| Hydraulic pump capacity (L/min) | 47/64 | 47/64 | 64 | 64 | 64 |
| 3-Point Hitch control | mech/ehr | mech/ehr | mech/ehr | mech/ehr | mech/ehr |
| 3-point hitch max load (kg) | 2670 | 2670 | 2670 | 2670 | 2670 |
| PTO speed (rpm) | 540/750 | 540/750 | 540/750/1000 | 540/750/1000 | 540/750/1000 |
| Disc brake type (dry / wet) | – | – | – | – | – |
| Type of control of the braking system | hydr | hydr | hydr | hydr | hydr |
| Turning radius 2WD (m) | 7,26 | 7,26 | 7,26 | – | – |
| Turning radius 4WD (m) | 7,6 | 7,6 | 7,6 | 7,9 | 7,9 |
Advertisement
| Front wheel 2WD | – | – | – | – | – |
| Front wheel 4WD | 335/80R18 | 405/70R20 | 11,2R24 | 405/70R20 | 405/70R20 |
| Rear wheel 2WD | – | – | – | – | – |
| Rear wheel 4WD | 480/70R28 | 540/65R30 | 16,9R30 | 540/65R30 | 540/65R30 |
| 2WD total weight (kg) | 2535 | 2585 | 2585 | – | – |
| 4WD total weight (kg) | 2845 | 2855 | 2855 | 3050 | 3050 |
| Total height with cabin (cm) | 234 | 234 | 234 | 234 | 234 |
| Total length (cm) | 366 | 366 | 366 | 378 | 378 |
| Total width (cm) | 213/207 | 213/207 | 213/207 | 226/219 | 219 |
| Fuel tank capacity (l) | 75 | 75 | 75 | 90 | 90 |
| Cabin sound level (dB) | 78 | 78 | 79 | 78 | 78 |
