Technical specifications of the agricultural tractor Same Dorado 55/65/75/85:
Advertisement
| Model | Same Dorado 55 | Same Dorado 65 | Same Dorado 75 | Same Dorado 85 |
| Years of production | 2000-2004 | 1999-2004 | 2000-2004 | 2000-2004 |
| Engine model / type | 1000.3A5 | 1000.3AT | 1000.4A5 | 1000.41AT |
| Number of cylinders / turbocharging | 3 | 3T | 4 | 4T |
| Engine displacement (cm3) | 3000 | 3000 | 4000 | 4000 |
| Piston dimension / stroke (mm) | 105×115,5 | 105×115,5 | 105×115,5 | 105×115,5 |
| Maximum engine power (hp) / rpm | 56/2350 | 63/2350 | 72/2350 | 83/2350 |
| Torque (Nm) / rpm | 197/1400 | 225/1450 | 276/1400 | 310/1400 |
| Number of gears (front + rear) | 16+8/20+10 | 16+8/20+10 | 20+10/24+12 | 20+10/30+15 |
| Number of synchronized gears (front+rear) | 16+8/20+10 | 16+8/20+10 | 20+10/24+12 | 20+10/30+15 |
Advertisement
| Speed-Shift | – | – | – | – |
| Type of reverse | – | – | – | – |
| Driving speed (km/h) | – | – | – | – |
| Max Driving speed (km/h) | 40 | 40 | 40 | 40 |
| Hydraulic pump capacity (L/min) | 36/48 | 36/48 | 36/48 | 36/48 |
| 3-Point Hitch control | mech/ehr | mech/ehr | mech/ehr | mech/ehr |
| 3-point hitch max load (kg) | 2900 | 2900 | 2900/3600 | 2900/3600 |
| PTO speed (rpm) | 540/1000 | 540/1001 | 540/1002 | 540/1003 |
| Disc brake type (dry / wet) | – | – | – | – |
| Type of control of the braking system | – | – | – | – |
| Turning radius 2WD (m) | 6,12 | 6,12 | 6,4 | 6,4 |
| Turning radius 4WD (m) | 7,3 | 7,3 | 7,6 | 7,6 |
Advertisement
| Front wheel 2WD | 6.50-20 | 7.50-16 | 7.50-20 | 7.50-20 |
| Front wheel 4WD | 11.2R24 | 320/70R20 | 11.2R24 | 320/70R24 |
| Rear wheel 2WD | 12.4R36 | 420/70R28 | 13.6R36 | 13.6R36 |
| Rear wheel 4WD | 12.4R36 | 420/70R28 | 480/70R30 | 480/70R30 |
| 2WD total weight (kg) | 2600 | 2600 | 2660 | 2660 |
| 4WD total weight (kg) | 2850 | 2850 | 2890 | 2890 |
| Total height with cabin (cm) | 240 | 240 | 244 | 244 |
| Total length (cm) | 370 | 370 | 385 | 385 |
| Total width (cm) | 211/206 | 211/206 | 224/219 | 224/219 |
| Fuel tank capacity (l) | 90 | 90 | 90 | 90 |
| Cabin sound level (dB) | 76 | 76 | 76 | 76 |
