Same Dorado 55

Same Dorado 55, 65, 75, 85 – specs, opinions & photos

Looking for information about agricultural tractors Same Dorado 55, 65, 75, 85? In this article, you'll find answers to questions such as:

  • How much horsepower does each model have?
  • What is the engine capacity of these models?
  • What is the hydraulic pump output for each one?
  • What is the PTO speed of these tractors?

With a spec sheet presented in table form, comparing the tractors is quick and easy, and user reviews will help you make the right choice.

Table of contents:

Technical specifications of the agricultural tractors Same Dorado 55, 65, 75, 85:

Same Dorado 55
Same Dorado 65
Same Dorado 75
Same Dorado 85

Same Dorado 55

  • Years of production: 2000-2004
  • Maximum engine power (HP) / at RPM: 56/2350
  • Number of gearbox speeds (forward + reverse): 16+8/20+10
  • Maximum speed (km/h): 40
  • Fuel tank capacity (L): 90

Same Dorado 65

  • Years of production: 1999-2004
  • Maximum engine power (HP) / at RPM: 63/2350
  • Number of gearbox speeds (forward + reverse): 16+8/20+10
  • Maximum speed (km/h): 40
  • Fuel tank capacity (L): 90

Same Dorado 75

  • Years of production: 2000-2004
  • Maximum engine power (HP) / at RPM: 72/2350
  • Number of gearbox speeds (forward + reverse): 20+10/24+12
  • Maximum speed (km/h): 40
  • Fuel tank capacity (L): 90

Same Dorado 85

  • Years of production: 2000-2004
  • Maximum engine power (HP) / at RPM: 83/2350
  • Number of gearbox speeds (forward + reverse): 20+10/30+15
  • Maximum speed (km/h): 40
  • Fuel tank capacity (L): 90

For details and a comparison of the tractors, see the technical sheet below.

Advertisement


Technical Data Sheet for Same Dorado 55, 65, 75, 85 tractors:

Comparison of technical parameters of agricultural tractors
Model Same Dorado 55 Same Dorado 65 Same Dorado 75 Same Dorado 85
Years of production 2000-2004 1999-2004 2000-2004 2000-2004
Engine designation/type 1000.3A5 1000.3AT 1000.4A5 1000.41AT
Number of cylinders / Turbo / Intercooler 3 3T 4 4T
Engine displacement (cm³) 3000 3000 4000 4000
Piston diameter / Stroke (mm) 105×115,5 105×115,5 105×115,5 105×115,5
Maximum engine power (HP) / at RPM 56/2350 63/2350 72/2350 83/2350
Torque (Nm) / at RPM 197/1400 225/1450 276/1400 310/1400
Number of gearbox speeds (forward + reverse) 16+8/20+10 16+8/20+10 20+10/24+12 20+10/30+15
Number of synchronized gears (forward + reverse) 16+8/20+10 16+8/20+10 20+10/24+12 20+10/30+15

Advertisement

Fast gearbox / Power shift – – – –
Reverser type – – – –
Speed range (km/h) – – – –
Maximum speed (km/h) 40 40 40 40
Hydraulic pump capacity (L/min) 36/48 36/48 36/48 36/48
Rear three-point hitch (TUV) control type mech/ehr mech/ehr mech/ehr mech/ehr
Maximum rear three-point hitch (TUV) lift capacity (kg) 2900 2900 2900/3600 2900/3600
Power take-off (PTO) speed (RPM) 540/1000 540/1001 540/1002 540/1003
Type of disc brake (dry/wet) – – – –
Brake system control type – – – –
Turning radius 2WD (m) 6,12 6,12 6,4 6,4
Turning radius 4WD (m) 7,3 7,3 7,6 7,6

Advertisement

Front tire size 2WD 6.50-20 7.50-16 7.50-20 7.50-20
Front tire size 4WD 11.2R24 320/70R20 11.2R24 320/70R24
Rear tire size 2WD 12.4R36 420/70R28 13.6R36 13.6R36
Rear tire size 4WD 12.4R36 420/70R28 480/70R30 480/70R30
Total weight 2WD (kg) 2600 2600 2660 2660
Total weight 4WD (kg) 2850 2850 2890 2890
Total height with cabin (cm) 240 240 244 244
Total length (cm) 370 370 385 385
Total width (cm) 211/206 211/206 224/219 224/219
Fuel tank capacity (L) 90 90 90 90
Cabin noise level (dB) 76 76 76 76
