Same Iron3 210, 190, 220 ⚙️ Specs

Technical specifications of the agricultural tractor Same Iron3 210/190/220:

Advertisement

Model Same Iron3 210 Same Iron3 190 Same Iron3 220
Years of production 2010-13 2010-13
Engine model / type TCD2013L06 2V DCR TCD2013L06 2V DCR TCD2013L06 2V DCR
Number of cylinders / turbocharging 6TI 6TI 6TI
Engine displacement (cm3) 7146 7146 7146
Piston dimension / stroke (mm) 108×130 108×130 108×130
Maximum engine power (hp) / rpm 197/2350 189/2350 213/2350
Torque (Nm) / rpm 836/1500 793/1500 836/1500
Number of gears (front + rear) 27+27 33+33 33+33
Number of synchronized gears (front+rear) 27+27 33+33 33+33

Advertisement

Speed-Shift 9 12 12
Type of reverse hydr hydr hydr
Driving speed (km/h) 0,6-40,0 0,65-66,5 0,6-66,5
Max Driving speed (km/h) 40 40/50/65 40/50/65
Hydraulic pump capacity (L/min) 113 113 113
3-Point Hitch control ehr ehr ehr
3-point hitch max load (kg) 10000 10000 10000
PTO speed (rpm) 750/1000 750/1000 750/1000
Disc brake type (dry / wet)
Type of control of the braking system
Turning radius 2WD (m)
Turning radius 4WD (m) 11,3 11,3 11,3

Advertisement

Front wheel 2WD
Front wheel 4WD 540/65R34 540/65R34 540/65R34
Rear wheel 2WD
Rear wheel 4WD 650/65R42 650/65R42 650/65R42
2WD total weight (kg)
4WD total weight (kg) 7520 7236 7236
Total height with cabin (cm) 302 303 303
Total length (cm) 480 501 501
Total width (cm) 299 299 299
Fuel tank capacity (l) 380 380 380
Cabin sound level (dB) 72 72 72
