Technical specification of agricultural tractor Same Leone/Saturno /Ariete :
Model | Same Leone | Same Saturno | Same Ariete |
Years of production | 1967-72 | 1976-80 | 1966-73 |
Engine model / type | 024-1004V | 039-1054P | DA 1154 |
Number of cylinders / turbocharging | V4 | 4 | 4 |
Engine displacement (cm3) | 3770 | 4156 | 4980 |
Piston dimension / stroke (mm) | 100×120 | 105×120 | 115×120 |
Maximum engine power (hp) / rpm | 67/2200 | 80/2200 | 85/2000 |
Torque (Nm) / rpm | 230/1700 | 275/1490 | 320/1400 |
Number of gears (front + rear) | 8+4 | 8+4 | 8+4 |
Number of synchronized gears (front+rear) | 8+4 | 8+4 | 8+4 |
Speed-Shift | – | – | – |
Type of reverse | – | – | – |
Driving speed (km/h) | 1,1-23,3 | 2,8-32,1 | 2,2-32,3 |
Max Driving speed (km/h) | 25 | 25 | 25 |
Hydraulic pump capacity (L/min) | 20 | 26 | 28 |
3-Point Hitch control | mech | mech | mech |
3-point hitch max load (kg) | 2000 | 2800 | 2400 |
PTO speed (rpm) | 540 | 540 | 540 |
Disc brake type (dry / wet) | – | – | – |
Type of control of the braking system | – | – | – |
Turning radius 2WD (m) | – | – | – |
Turning radius 4WD (m) | – | – | – |
Front wheel 2WD | – | – | – |
Front wheel 4WD | – | – | – |
Rear wheel 2WD | – | – | – |
Rear wheel 4WD | – | – | – |
2WD total weight (kg) | 2480 | 3350 | 3120 |
4WD total weight (kg) | 2630 | 3600 | 3560 |
Total height with cabin (cm) | 246 | 159 | – |
Total length (cm) | 331/335 | (387/394) | 378 |
Total width (cm) | 218/214 | 235 | 247/245 |
Fuel tank capacity (l) | 90 | 85 | 86 |
Cabin sound level (dB) | 96 | – | – |
Add an opinion about Same Leone/Saturno /Ariete:
Rate this article :
Like us on facebook:
SAME was founded by Eugenio and Francesco Cassani in 1942 in Treviglio. It was a very risky venture due to the ongoing World War, which resulted in a shortage of raw materials for production. The first SAME tractor, with a power of just 10 hp, was produced in 1948. Today SAME is one of the world’s leading makers of agricultural tractors.
