Technical Specifications of the FiatAgri Laverda 1950 Combine Harvester:
FiatAgri Laverda 1950 Combine Harvester was produced from 2000 to 2001. It is equipped with an Iveco 8065 SRE10 engine with a displacement of 5861 cm³, turbocharged, generating 196 HP. It has a 350-liter fuel tank and a hydrostatic transmission with four speeds, allowing a driving speed from 0 to 25 km/h. The cutting unit has a working width of 420 cm, and inside the combine, there are five straw walkers. The overall dimensions are 830 cm in length, 320 cm in width without the cutting unit, and 398 cm in height with the cab. The grain tank capacity is 70 hectoliters. The FiatAgri Laverda 1950 combine harvester is equipped with front wheels of size 650/75R30 and rear wheels of size 12.5-18.
Advertisement
Data sheet for FiatAgri Laverda 1950 – 2760 MCS combine harvesters:
| Model | FiatAgri Laverda 1950 | FiatAgri Laverda 2050 MCS | FiatAgri Laverda 2350 MCS | FiatAgri Laverda 2560 MCS | FiatAgri Laverda 2760 MCS |
| Years of production | 2000-2001 | 2000-2001 | 2000-2001 | 2000-2001 | 2000-2001 |
| Engine manufacturer | Iveco | Iveco | Iveco | Iveco | Iveco |
| Engine model / type | 8065 SRE10 | 8065 SRE10 | 8361 SRE10 | 8361 SRE10 | 8361 SRE11 |
| Engine displacement (cm3) | 5861 | 5861 | 8102 | 8102 | 8102 |
| Number of cylinders / turbocharging | 6T | 6T | 6T | 6T | 6T |
| Engine rated power (hp) | 196 | 196 | 235 | 235 | 270 |
| Fuel tank capacity (l) | 350 | 350 | 450 | 450 | 450 |
| Type of drive transmission | hydr | hydr | hydr | hydr | hydr. |
| Number of gears (front + rear) | 4 | 4 | 4 | 4 | 4 |
| Driving speed min-max (km/h) | 0-25 | 0-25 | 0-25 | 0-25 | 0-25 |
Advertisement
| Cutting unit working width (cm) | 420 | 420 | 540 | 600 | 600 |
| Number of straw walkers | 5 | 5 | 5 | 6 | 6 |
| Total length (cm) | 830 | 830 | 830 | 830 | 830 |
| Total width (cm) | – | – | – | – | – |
| Width without cutting attachment (cm) | 320 | 320 | 320 | 348 | 348 |
| Height without cabin (cm) | – | – | – | – | – |
| Total height with cabin (cm) | 398 | 398 | 398 | 390 | 390 |
| Weight without cabin (kg) | – | – | – | – | – |
| Weight with cabin (kg) | – | – | – | – | – |
| Grain tank capacity (hl) | 70 | 70 | 75 | 75 | 75 |
| Front wheel size | 650/75R30 | 650/75R30 | 650/75R30 | 650/75R30 | 650/75R30 |
| Rear wheel size | 12.5-18 | 12.5-18 | 12.5-18 | 12.5-18 | 12.5-18 |
