Technical specifications of Sampo 2020 Combine Harvester:
Sampo 2020 Combine Harvester was produced between 1990 and 1996. It was equipped with a Valmet engine with a capacity of 4400 cm³ and 79 HP. The engine has four cylinders. The combine harvester has a mechanical gearbox with three gears, allowing speeds from 1.6 to 22 km/h. The cutting unit has a working width of 270 cm, and there are four straw walkers inside the combine. Its dimensions are 755 cm in length, 305 cm in width, and 330 cm in height with the cab. The weight with the cab is 4300 kg. The grain tank has a capacity of 25 hectoliters. The front wheels measure 16.9R28, and the rear wheels are 11.5-15. The fuel tank capacity is 140 liters.
Table of contents:
Advertisement
Data sheet for Sampo 2020, 2025 combine harvesters:
| Model | Sampo 2020 | Sampo 2025 |
| Years of production | 1990-96 | 1990-96 |
| Engine manufacturer | Valmet | Valmet |
| Engine model / type | – | – |
| Engine displacement (cm3) | 4400 | 4400 |
| Number of cylinders / turbocharging | 4 | 4 T |
| Engine rated power (hp) | 79 | 87 |
| Fuel tank capacity (l) | 140 | 140 |
| Type of drive transmission | mech | hydr |
| Number of gears (front + rear) | 3 | 3 |
| Driving speed min-max (km/h) | 1,6-22 | 0-24 |
Advertisement
| Cutting unit working width (cm) | 270 | 310 |
| Number of straw walkers | 4 | 4 |
| Total length (cm) | 755 | 755 |
| Total width (cm) | 305 | 335 |
| Width without cutting attachment (cm) | – | – |
| Height without cabin (cm) | – | – |
| Total height with cabin (cm) | 330 | 330 |
| Weight without cabin (kg) | – | – |
| Weight with cabin (kg) | 4300 | 4500 |
| Grain tank capacity (hl) | 25 | 25 |
| Front wheel size | 16,9R28 | 16,9R34 |
| Rear wheel size | 11,5-15 | 11,2R20 |
Advertisement
Add your opinion and share the fuel consumption of the combine Sampo 2020, 2025:
Sampo 2020, 2025 Gallery:
