Technical specification of the Claas Scorpion 6040 telescopic handler:
The Claas Scorpion 6040 telescopic handler was produced from 2005 to 2007. It is equipped with a Deutz engine model BF4M2012, delivering a nominal power of 136 HP. It has a HY-type drive transmission, allowing it to reach a travel speed of up to 40 km/h. The maximum lifting height of the handler is 6.25 meters, with a maximum load capacity of 3600 kg. The total weight of the machine is 7800 kg. The handler’s dimensions are: length 476 cm, width 239 cm, and height 249 cm. It is equipped with 400/80-24 wheels.
Table of contents:
Advertisement
Data sheet for Claas Scorpion 6040, 7030, 7030 Special telescopic handlers:
| Model | Claas Scorpion 6040 | Claas Scorpion 7030 | Claas Scorpion 7030 Special |
| Years of production | 2005-2007 | 2005-2007 | 2012-2013 |
| Engine manufacturer | Deutz | Deutz | Deutz |
| Engine model / type | BF4M2012 | BF4M2012 | TCD2012L042V |
| Engine rated power (hp) | 136KM | 122KM | 120KM |
| Type of drive transmission | HY | HY | HY |
| Driving speed (km/h) | 40km/h | 40km/h | 32km/h |
| Maximum lifting height (m) | 6,25m | 7,1m | 7,1m |
| Maximum load capacity (kg) | 3600kg | 3200kg | 3500kg |
| Total weight | 7800kg | 7500kg | 7500kg |
| Size of the wheels | 400/80-24 | 400/80-24 | 460/70-24 |
| Total length (cm) | 476cm | 476cm | 476cm |
| Total width (cm) | 239cm | 239cm | 239cm |
| Total height (cm) | 249cm | 249cm | 249cm |
