Technical specifications of the agricultural tractor Same Virtus 100/110/120/130:
Advertisement
| Model | Same Virtus 100 | Same Virtus 110 | Same Virtus 120 | Same Virtus 130 |
| Years of production | 2013- | 2013- | 2013- | 2013- |
| Engine model / type | TCD | TCD | TCD | TCD |
| Number of cylinders / turbocharging | 4TI | 4TI | 4TI | 4TI |
| Engine displacement (cm3) | 3620 | 3620 | 3620 | 3620 |
| Piston dimension / stroke (mm) | 98×120 | 98×120 | 98×120 | 98×120 |
| Maximum engine power (hp) / rpm | 95/2200 | 105/2200 | 116/2200 | 120/2200 |
| Torque (Nm) / rpm | 397/1600 | 440/1600 | 460/1600 | 480/1600 |
| Number of gears (front + rear) | 10+10/30+30 | 10+10/30+30 | 10+10/30+30 | 10+10/30+30 |
| Number of synchronized gears (front+rear) | 10+10/30+30 | 10+10/30+30 | 10+10/30+30 | 10+10/30+30 |
Advertisement
| Speed-Shift | 3 | 3 | 3 | 3 |
| Type of reverse | hydr | hydr | hydr | hydr |
| Driving speed (km/h) | – | – | – | – |
| Max Driving speed (km/h) | 40/40 (50) | 40/40 (50) | 40/40 (50) | 40/40 (50) |
| Hydraulic pump capacity (L/min) | 60 (90) | 60 (90) | 60 (90) | 60 (90) |
| 3-Point Hitch control | ehr | ehr | ehr | ehr |
| 3-point hitch max load (kg) | 4650 (6600) | 4650 (6600) | 4650 (6600) | 4650 (6600) |
| PTO speed (rpm) | 540/750/ | 540/750/ | 540/750/ | 540/750/ |
| Disc brake type (dry / wet) | – | – | – | – |
| Type of control of the braking system | – | – | – | – |
| Turning radius 2WD (m) | – | – | – | – |
| Turning radius 4WD (m) | 7 | 7 | 7 | 7 |
Advertisement
| Front wheel 2WD | – | – | – | – |
| Front wheel 4WD | 420/70R24 | 480/65R24 | 420/70R28 | 440/65R28 |
| Rear wheel 2WD | 520/70R34 | – | – | |
| Rear wheel 4WD | 480/70R34 | 520/70R34 | 520/70R38 | 540/65R38 |
| 2WD total weight (kg) | – | – | – | – |
| 4WD total weight (kg) | 4500 | 4600 | 4900 | 5000 |
| Total height with cabin (cm) | 266 | 266 | 272 | 271 |
| Total length (cm) | 427 | 427 | 427 | 427 |
| Total width (cm) | 243 | 243 (2WD 239) | 244 | 244 |
| Fuel tank capacity (l) | 165 | 165 | 165 | 165 |
| Cabin sound level (dB) | 73 | 73 | 73 | 73 |
