Valmet 33, 359 ⚙️ Specs

Technical Specifications of the Valmet 33 Agricultural Tractor:

Valmet 33 Agricultural Tractor was manufactured between 1957 and 1959. It is equipped with a 309 D engine with a displacement of 2,685 cm³, a three-cylinder naturally aspirated engine without a turbocharger or intercooler. The cylinder bore is 100 mm, and the piston stroke is 114 mm. The engine delivers a maximum power of 37 HP, with a torque of 140 Nm at 1,200 rpm. The transmission features 6 forward gears and 2 reverse gears. The speed range is from 3.3 to 28.5 km/h. The hydraulic system has a capacity of 18 L/min and mechanical control for the rear lift, with a maximum lifting capacity of 1,200 kg. The power take-off (PTO) operates at 540 rpm. The 2WD version comes with 6.00-19 front tires and 12.4/11-28 rear tires. The total weight of the 2WD version is 1,700 kg. The total height with the cab is 135 cm, the length is 296 cm, and the width is 190 cm. The fuel tank capacity is 40 liters.

Advertisement

Technical Data Sheet for Valmet 33, 359 Agricultural Tractors:

Model Valmet 33 Valmet 359
Years of production 1957-59 1959-60
Engine model / type 309 D 309 D
Number of cylinders / turbocharging 3 3
Engine displacement (cm3) 2685 2685
Piston dimension / stroke (mm) 100×114 100×114
Maximum engine power (hp) / rpm 37 37,5
Torque (Nm) / rpm 140/1200
Number of gears (front + rear) 6+2 6+2
Number of synchronized gears (front+rear)

Advertisement

Speed-Shift
Type of reverse
Driving speed (km/h) 3,3-28,5 3,3-28,5
Max Driving speed (km/h)
Hydraulic pump capacity (L/min) 18
3-Point Hitch control mech mech
3-point hitch max load (kg) 1200 1200
PTO speed (rpm) 540 540
Disc brake type (dry / wet)
Type of control of the braking system
Turning radius 2WD (m)
Turning radius 4WD (m)

Advertisement

Front wheel 2WD 6,00-19 6,00-19
Front wheel 4WD
Rear wheel 2WD 12,4/11-28 12,4/11-28
Rear wheel 4WD
2WD total weight (kg) 1700 1750
4WD total weight (kg)
Total height with cabin (cm) 135 135
Total length (cm) 296 296
Total width (cm) 190 190
Fuel tank capacity (l) 40 40
Cabin sound level (dB)
