Technical specifications of the combine harvesters FiatAgri Laverda M 303, M 304, M 305, M 306:
FiatAgri Laverda M 303
- Years of production: –
- Rated engine power (HP): 255
- Fuel tank capacity (L): 450
- Cutting unit/header working width (cm): 480
- Grain tank capacity (hl): 82
FiatAgri Laverda M 304
- Years of production: –
- Rated engine power (HP): 275
- Fuel tank capacity (L): 450
- Cutting unit/header working width (cm): 540
- Grain tank capacity (hl): 90
FiatAgri Laverda M 305
- Years of production: –
- Rated engine power (HP): 275
- Fuel tank capacity (L): 450
- Cutting unit/header working width (cm): 600
- Grain tank capacity (hl): 82
FiatAgri Laverda M 306
- Years of production: –
- Rated engine power (HP): 305
- Fuel tank capacity (L): 450
- Cutting unit/header working width (cm): 600
- Grain tank capacity (hl): 90
For details and a comparison of the combines, see the technical sheet below.
Advertisement
Data sheet for FiatAgri Laverda M306, M303, M304, M305 combine harvesters:
| Model | FiatAgri Laverda M 303 | FiatAgri Laverda M 304 | FiatAgri Laverda M 305 | FiatAgri Laverda M 306 |
|---|---|---|---|---|
| Years of production | – | – | – | – |
| Engine manufacturer | Iveco | CAT | CAT | CAT |
| Engine designation/type | NEF | 3126 | 3126 | 3126 |
| Engine displacement (cm³) | 5861 | 7241 | 7241 | 7241 |
| Number of cylinders / turbocharging | 6T | 6T | 6T | 6T |
| Rated engine power (HP) | 255 | 275 | 275 | 305 |
| Fuel tank capacity (L) | 450 | 450 | 450 | 450 |
| Type of transmission system | hydr | hydr | hydr | hydr |
| Number of gearbox speeds | 4 | 4 | 4 | 4 |
| Minimum-maximum driving speed (km/h) | 0-25 | 0-25 | 0-25 | 0-25 |
Advertisement
| Cutting unit/header working width (cm) | 480 | 540 | 600 | 600 |
|---|---|---|---|---|
| Number of straw walkers | 5 | 5 | 6 | 6 |
| Total length (cm) | – | – | – | – |
| Total width (cm) | – | – | – | – |
| Width without cutting unit/header (cm) | 331 | 358 | 357 | 384 |
| Height without cab (cm) | – | – | – | – |
| Total height with cab (cm) | 400 | 400 | 400 | 400 |
| Weight without cab (kg) | – | – | – | – |
| Weight with cab (kg) | – | – | – | – |
| Grain tank capacity (hl) | 82 | 90 | 82 | 90 |
| Front wheel size | 650/75R32 | 800/65R32 | 650/75R32 | 800/65R32 |
| Rear wheel size | 460/70R24 | 460/70R24 | 460/70R24 | 460/70R24 |
