Technical specifications of the agricultural tractor Case IH Farmall 55 C/65 C/75 C/85 C EP/95 C EP/105 C EP/115 C EP:
Advertisement
| Model | Case IH Farmall 55 C | Case IH Farmall 65 C | Case IH Farmall 75 C | Case IH Farmall 85 C EP | Case IH Farmall 95 C EP | Case IH Farmall 105 C EP | Case IH Farmall 115 C EP |
| Years of production | 2011- | 2011- | 2011- | 2013- | 2013- | 2013- | 2014- |
| Engine model / type | F5C | F5C | F5C | F5C | F5C | F5C | F5C |
| Number of cylinders / turbocharging | 4TI | 4TI | 4TI | 4TI | 4TI | 4TI | 4TI |
| Engine displacement (cm3) | 3200 | 3200 | 3200 | 3400 | 3400 | 3400 | 3400 |
| Piston dimension / stroke (mm) | 99×104 | 99×104 | 99×104 | 99×110 | 99×110 | 99×110 | 99×110 |
| Maximum engine power (hp) / rpm | 56/2300 | 65/2300 | 75/2300 | 86/2300 | 99/2300 | 107/2300 | 114/2300 |
| Torque (Nm) / rpm | 221/1400 | 260/1400 | 310/1250 | 351/1500 | 407/1500 | 444/1500 | 457/1500 |
| Number of gears (front + rear) | 12+12 | 12+12 | 12+12 | 12+12 (24+24) | 12+12 (24+24) | 12+12 (24+24) | 12+12 (24+24) |
| Number of synchronized gears (front+rear) | 12+12 | 12+12 | 12+12 | 12+12 (24+24) | 12+12 (24+24) | 12+12 (24+24) | 12+12 (24+24) |
Advertisement
| Speed-Shift | – | – | – | – | – | – | – |
| Type of reverse | mech/hydr | mech/hydr | mech/hydr | mech/hydr | mech/hydr | mech/hydr | mech/hydr |
| Driving speed (km/h) | 0,8-39,2 | 0,8-39,2 | 0,8-39,2 | 2,1-40 | 2,1-40 | 2,1-40 | 2,1-40 |
| Max Driving speed (km/h) | – | – | – | – | – | – | – |
| Hydraulic pump capacity (L/min) | 48 | 48 | 48 | 64 (48) | 64 (48) | 64 (48) | 64 (48) |
| 3-Point Hitch control | mech | mech | mech | ehr | ehr | ehr | ehr |
| 3-point hitch max load (kg) | 2800 | 2800 | 2800 | 3900 | 3900 | 3900 | 3900 |
| PTO speed (rpm) | 540/750 | 540/750 | 540/750 | 540 | 540 | 540 | 540 |
| Disc brake type (dry / wet) | – | – | – | – | – | – | – |
| Type of control of the braking system | – | – | – | – | – | – | – |
| Turning radius 2WD (m) | – | – | – | – | – | – | – |
| Turning radius 4WD (m) | 7,5 | 7,5 | 7,5 | 8,48 | 8,48 | 8,48 | 8,48 |
Advertisement
| Front wheel 2WD | 7.50-16 | 7.50-16 | 7.50-16 | – | – | – | – |
| Front wheel 4WD | 14.9LR20 | 14.9LR20 | 14.9LR20 | 11.2R24 | 13.6R24 | 13.6R24 | 13.6R24 |
| Rear wheel 2WD | 16.9R30 | 16.9R30 | 16.9R30 | – | – | – | – |
| Rear wheel 4WD | 16.9R30 | 16.9R30 | 16.9R30 | 16.9R30 | 16.9R34 | 16.9R34 | 16.9R34 |
| 2WD total weight (kg) | 2520 | 2520 | 2520 | – | – | – | – |
| 4WD total weight (kg) | 2800 | 2800 | 2800 | 3600 | 3700 | 3700 | 3700 |
| Total height with cabin (cm) | 250 | 250 | 250 | 254 | 259 | 259 | 259 |
| Total length (cm) | 400 | 400 | 400 | 424 | 424 | 424 | 424 |
| Total width (cm) | 210 | 210 | 210 | 226 | 226 | 226 | 226 |
| Fuel tank capacity (l) | 90 | 90 | 90 | 115 | 115 | 115 | 115 |
| Cabin sound level (dB) | 76 | 76 | 76 | 76 | 76 | 76 | 76 |
