Technical specifications of the agricultural tractor John Deere 6170R/6190R/6210R/6175R/6195R/6215R/6230R/6250R:
Advertisement
| Model | John Deere 6170R | John Deere 6190R | John Deere 6210R | John Deere 6175R | John Deere 6195R | John Deere 6215R | John Deere 6230R | John Deere 6250R |
| Years of production | 2011-14 | 2011-14 | 2011-14 | 2014- | 2014- | 2014- | 2016- | 2016- |
| Engine model / type | PVX | PVX | PVX | PVS | PSS | PSS | PSS | PSS |
| Number of cylinders / turbocharging | 6TI | 6TI | 6TI | 6TI | 6TI | 6TI | 6TI | 6TI |
| Engine displacement (cm3) | 6788 | 6788 | 6788 | 6788 | 6788 | 6788 | 6788 | 6788 |
| Piston dimension / stroke (mm) | 106,5×127 | 106,5×127 | 106,5×127 | 106,5×127 | 106,5×127 | 106,5×127 | 106,5×127 | 106,5×127 |
| Maximum engine power (hp) / rpm | 162/2100 | 181/2100 | 200/2100 | 166/2100 | 185/2100 | 204/2100 | 220/2100 | 239/2100 |
| Torque (Nm) / rpm | – | – | – | – | – | – | – | – |
| Number of gears (front + rear) | – | – | – | – | – | – | – | – |
| Number of synchronized gears (front+rear) | hydr | hydr | hydr | hydr | hydr | hydr | hydr | hydr |
Advertisement
| Speed-Shift | 2,5-40 | 2,5-40 | 2,5-40 | 2,5-40 | 2,5-40 | 2,5-40 | 0,05-40 | 0,05-40 |
| Type of reverse | 40 (50) | 40 (50) | 40 (50) | 40 (50) | 40 (50) | 40 (50) | 40 (50) | 40 (50) |
| Driving speed (km/h) | – | – | – | – | – | – | – | – |
| Max Driving speed (km/h) | – | – | – | – | – | – | – | – |
| Hydraulic pump capacity (L/min) | 114 (155) | 114 (155) | 114 (155) | 114 (155) | 114 (155) | 114 (155) | 160 | 160 |
| 3-Point Hitch control | ehr | ehr | ehr | ehr | ehr | ehr | ehr | ehr |
| 3-point hitch max load (kg) | 8500 | 8500 | 8500 | 8500 | 8500 | 9550 | 10400 | 10400 |
| PTO speed (rpm) | 540/750/ | 540/750/ | 540/750/ | 540/750/ | 540/750/ | 540/750/ | 540/750/ | 540/750/ |
| Disc brake type (dry / wet) | – | – | – | – | – | – | – | – |
| Type of control of the braking system | – | – | – | – | – | – | – | – |
| Turning radius 2WD (m) | – | – | – | – | – | – | – | – |
| Turning radius 4WD (m) | 11,4 | 11,4 | 11,4 | 11,4 | 11,4 | 11,4 | 11,4 | 11,4 |
Advertisement
| Front wheel 2WD | – | – | – | – | – | – | – | – |
| Front wheel 4WD | – | – | – | – | – | – | – | – |
| Rear wheel 2WD | – | – | – | – | – | – | – | – |
| Rear wheel 4WD | – | – | – | – | – | – | – | – |
| 2WD total weight (kg) | – | – | – | – | – | – | – | – |
| 4WD total weight (kg) | 7350 | 7375 | 7400 | 8300 | 8400 | 8500 | 9300 | 9300 |
| Total height with cabin (cm) | 316 | 316 | 316 | 316 | 316 | 316 | 325 | 325 |
| Total length (cm) | 505 | 505 | 505 | 505 | 505 | 505 | 519 | 519 |
| Total width (cm) | 280 | 280 | 280 | 280 | 280 | 280 | 290 | 290 |
| Fuel tank capacity (l) | 455 | 455 | 455 | 395+AB20 | 395+AB20 | 395+AB20 | 470+AB | 470+AB |
| Cabin sound level (dB) | 72 | 72 | 72 | 70,7 | 70,7 | 70,7 | 71 | 71 |
