Technical specifications of the agricultural tractor Valtra M120/M120e/M130/M150/XM130/XM150:
Advertisement
| Model | Valtra M120 | Valtra M120e | Valtra M130 | Valtra M150 | Valtra XM130 | Valtra XM150 |
| Years of production | – | – | – | – | – | – |
| Engine model / type | 44EWA | 44EWA | 44EWA | 44EWA | 44EWA | 44EWA |
| Number of cylinders / turbocharging | 4TI | 4TI | 4TI | 4TI | 4TI | 4TI |
| Engine displacement (cm3) | 4399 | 4399 | 4399 | 4399 | 4399 | 4399 |
| Piston dimension / stroke (mm) | 108×120 | 108×120 | 108×120 | 108×120 | 108×120 | 108×120 |
| Maximum engine power (hp) / rpm | 120/2200 | 120/1800 | 135/2200 | 150/2200 | 135/2200 | 150/2200 |
| Torque (Nm) / rpm | 500/1400 | 580/1200 | 510/1400 | 580/1400 | 510/1400 | 580/1400 |
| Number of gears (front + rear) | 36+36 | 36+36 | 36+36 | 36+36 | 36+36 | 36+36 |
| Number of synchronized gears (front+rear) | 36+36 | 36+36 | 36+36 | 36+36 | 36+36 | 36+36 |
Advertisement
| Speed-Shift | 3 | 3 | 3 | 3 | 3 | 3 |
| Type of reverse | hydr | hydr | hydr | hydr | hydr | hydr |
| Driving speed (km/h) | 0,6-40,1 | 0,6-40,1 | 0,6-40,1 | 0,6-40,1 | 0,6-40,1 | 0,6-40,1 |
| Max Driving speed (km/h) | 41 (50) | 40 | 41 (50) | 41 (50) | 41 | 41 |
| Hydraulic pump capacity (L/min) | 91 | 82 | 91 | 91 | 91 (181) | 91 (181) |
| 3-Point Hitch control | ehr | ehr | ehr | ehr | ehr | ehr |
| 3-point hitch max load (kg) | 7200 | 7200 | 7200 | 7200 | 7200 | 7200 |
| PTO speed (rpm) | 540/1000 | 540/1000 | 540/1000 | 540/1000 | 540/1000 | 540/1000 |
| Disc brake type (dry / wet) | – | – | – | – | – | – |
| Type of control of the braking system | – | – | – | – | – | – |
| Turning radius 2WD (m) | – | – | – | – | – | – |
| Turning radius 4WD (m) | 9,4 | 9,4 | 9,4 | 10,4 | 9,6 | 9,6 |
Advertisement
| Front wheel 2WD | – | – | – | – | – | – |
| Front wheel 4WD | 14.9R28 | 14.9R28 | 14.9R28 | 16.9R28 | 16.9R28 | 16.9R28 |
| Rear wheel 2WD | – | – | – | – | – | – |
| Rear wheel 4WD | 18.4R38 | 18.4R38 | 18.4R38 | 20.8R38 | 20.8R38 | 20.8R38 |
| 2WD total weight (kg) | – | – | – | – | – | – |
| 4WD total weight (kg) | 5130 | 5130 | 5130 | 5450 | 6150 | 6150 |
| Total height with cabin (cm) | 297 | 297 | 297 | 298 | 300 | 300 |
| Total length (cm) | 490 | 490 | 490 | 490 | 522 | 522 |
| Total width (cm) | 256 | 256 | 256 | 256 | 288 | 288 |
| Fuel tank capacity (l) | 165 | 165 | 165 | 165 | 250 | 250 |
| Cabin sound level (dB) | 73,5 | 71,5 | 75 | 74,5 | 73 | 71 |
