John Deere 7600, 7700, 7800 ⚙️ Specs

Technical specifications of the agricultural tractor John Deere 7600/7700/7800:

Advertisement

Model John Deere 7600 John Deere 7700 John Deere 7800
Years of production 92-97 92-97 92-97
Engine model / type 6068 6076 6076
Number of cylinders / turbocharging 6T 6T 6T
Engine displacement (cm3) 6786 7636 7636
Piston dimension / stroke (mm) 106,5×127 115,8×120,6 115,8×120,6
Maximum engine power (hp) / rpm 130/2100 150/2100 170/2100
Torque (Nm) / rpm 610/1220 670/1400 775/1400
Number of gears (front + rear) 20+12/19+7 20+12/19+7 20+12/19+7
Number of synchronized gears (front+rear) 20+12/19+7 20+12/19+7 20+12/19+7

Advertisement

Speed-Shift 4 4 4
Type of reverse hydr hydr hydr
Driving speed (km/h) 2,4-40/1,6-40 2,4-40/1,6-40 2,4-40/1,6-40
Max Driving speed (km/h)
Hydraulic pump capacity (L/min) 90 90 90
3-Point Hitch control ehr ehr ehr
3-point hitch max load (kg) 7982 7982 7982
PTO speed (rpm) 540/1000 540/1000 540/1000
Disc brake type (dry / wet)
Type of control of the braking system hydr hydr hydr
Turning radius 2WD (m)
Turning radius 4WD (m) 10,26 10,26 10,26

Advertisement

Front wheel 2WD
Front wheel 4WD 16,9R28 16,9R28 16,9R28
Rear wheel 2WD
Rear wheel 4WD 20,8R38 20,8R38 20,8R38
2WD total weight (kg)
4WD total weight (kg) 6490 6510 6590
Total height with cabin (cm) 301 301 301
Total length (cm) 475 475 475
Total width (cm) 280 280 280
Fuel tank capacity (l) 344 344 344
Cabin sound level (dB) 72 72 72
