Technical specifications of the agricultural tractor McCormick X70.40/X70.50/X70.60/X70.70/X70.80:
Advertisement
| Model | McCormick X70.40 | McCormick X70.50 | McCormick X70.60 | McCormick X70.70 | McCormick X70.80 |
| Years of production | 2012-13 | 2012-13 | 2012-13 | 2012-13 | 2012-13 |
| Engine model / type | BetaPower | BetaPower | BetaPower | BetaPower | BetaPower |
| Number of cylinders / turbocharging | 6TI | 6TI | 6TI | 6TI | 6TI |
| Engine displacement (cm3) | 6728 | 6728 | 6728 | 6728 | 6728 |
| Piston dimension / stroke (mm) | 104×132 | 104×132 | 104×132 | 104×132 | 104×132 |
| Maximum engine power (hp) / rpm | 150/2200 | 165/2200 | 175/2200 | 188/2200 | 214/2200 |
| Torque (Nm) / rpm | 632/1400 | 682/1400 | 726/1400 | 810/1400 | 912/1400 |
| Number of gears (front + rear) | 32+24 | 32+24 | 32+24 | 32+24 | 32+24 |
| Number of synchronized gears (front+rear) | 32+24 | 32+24 | 32+24 | 32+24 | 32+24 |
Advertisement
| Speed-Shift | 8 | 8 | 8 | 8 | 8 |
| Type of reverse | hydr | hydr | hydr | hydr | hydr |
| Driving speed (km/h) | 1,8-49,0 | 1,8-49,0 | 1,8-49,0 | 1,8-49,8 | 1,8-49,8 |
| Max Driving speed (km/h) | – | – | – | – | – |
| Hydraulic pump capacity (L/min) | 110 | 110 | 110 | 130 (163) | 130 (163) |
| 3-Point Hitch control | ehr | ehr | ehr | ehr | ehr |
| 3-point hitch max load (kg) | 7200 | 7200 | 7200 | 10950 | 10950 |
| PTO speed (rpm) | 540/1000 | 540/1000 | 540/1000 | 540/1000 | 540/1000 |
| Disc brake type (dry / wet) | – | – | – | – | – |
| Type of control of the braking system | – | – | – | – | – |
| Turning radius 2WD (m) | – | – | – | – | – |
| Turning radius 4WD (m) | 9,8 | 9,8 | 9,8 | 10,8 | 10,8 |
Advertisement
| Front wheel 2WD | – | – | – | – | – |
| Front wheel 4WD | 480/65R28 | 480/65R28 | 540/65R28 | 540/65R30 | 540/65R30 |
| Rear wheel 2WD | – | – | – | – | – |
| Rear wheel 4WD | 600/65R38 | 600/65R38 | 650/65R38 | 650/65R42 | 650/65R42 |
| 2WD total weight (kg) | – | – | – | – | – |
| 4WD total weight (kg) | 6500 | 6500 | 6500 | 7700 | 7700 |
| Total height with cabin (cm) | 290 | 290 | 290 | 300 | 300 |
| Total length (cm) | 521 | 521 | 521 | 531 | 531 |
| Total width (cm) | 275 | 275 | 275 | 287 | 287 |
| Fuel tank capacity (l) | 300+AB38 | 300+AB38 | 300+AB38 | 347+AB38 | 347+AB38 |
| Cabin sound level (dB) | 72 | 72 | 72 | 72 | 72 |
