Same Audax ST 200, ST 220 ⚙️ Specs

Technical Specifications of the Same Audax ST 200 Agricultural Tractor:

Same Audax ST 200 Agricultural Tractor has been in production since 2014. It is equipped with a six-cylinder TCD2013L06 2V DCR engine with a displacement of 6057 cm³, featuring a turbocharger and intercooler. The maximum power output is 189 HP at 2100 RPM, while the torque reaches 830 Nm at 1600 RPM. The transmission offers 33 synchronized forward and 33 reverse gears, with a hydraulic shuttle and a 12-speed high-range gearbox. The driving speed ranges from 0.65 to 66.5 km/h, with a maximum speed of 40, 50, or 65 km/h. The hydraulic system provides a pump capacity of 113 L/min, electronic rear hitch control, and a maximum lifting capacity of 10,000 kg. The power take-off (PTO) operates at 750 and 1000 RPM. The turning radius in the 4WD version is 11.3 m. The front tires are sized 540/65R34, while the rear tires are 650/65R42. The total weight of the tractor is 8250 kg, with a cabin height of 315 cm, a length of 501 cm, a width of 299 cm, and a fuel tank capacity of 510 liters, with an additional 50-liter AdBlue tank.

Advertisement

Technical Data Sheet for Same Audax ST 200, ST 220 Agricultural Tractors:

Model Same Audax ST 200 Same Audax ST 220
Years of production 2014- 2014-
Engine model / type TCD2013L06 2V DCR TCD2013L06 2V DCR
Number of cylinders / turbocharging 6TI 6TI
Engine displacement (cm3) 6057 6057
Piston dimension / stroke (mm) 101×126 101×126
Maximum engine power (hp) / rpm 189/2100 213/2100
Torque (Nm) / rpm 830/1600 900/1600
Number of gears (front + rear) 33+33 33+33
Number of synchronized gears (front+rear) 33+33 33+33

Advertisement

Speed-Shift 12 12
Type of reverse hydr hydr
Driving speed (km/h) 0,65-66,5 0,6-66,5
Max Driving speed (km/h) 40/50/65 40/50/65
Hydraulic pump capacity (L/min) 113 113
3-Point Hitch control ehr ehr
3-point hitch max load (kg) 10000 10000
PTO speed (rpm) 750/1000 750/1000
Disc brake type (dry / wet)
Type of control of the braking system
Turning radius 2WD (m)
Turning radius 4WD (m) 11,3 11,3

Advertisement

Front wheel 2WD
Front wheel 4WD 540/65R34 540/65R34
Rear wheel 2WD
Rear wheel 4WD 650/65R42 650/65R42
2WD total weight (kg)
4WD total weight (kg) 8250 8250
Total height with cabin (cm) 315 315
Total length (cm) 501 501
Total width (cm) 299 299
Fuel tank capacity (l) 510+AB50 510+AB50
Cabin sound level (dB)
