Technical specifications of the Braud 405 Combine Harvester:
Braud 405 Combine Harvester was produced from 1963 to 1967. It was equipped with a Perkins P6 engine with a capacity of 4730 cm³ and a power of 77 HP. It has six cylinders and a mechanical transmission with three gears, allowing it to travel at speeds from 1.7 to 18.0 km/h. The cutting unit has a working width of 280 cm, equipped with four straw walkers. The harvester has a grain tank with a capacity of 21 hectoliters. The dimensions of the harvester are 803 cm in length, 320 cm in width, and 329 cm in height without the cabin, and its weight is 4330 kg. The size of the front wheels is 13.6/12-28, and the rear wheels are 140-40 AT.
Table of contents:
Advertisement
Data sheet for Braud 405, 405-4, 405-6 combine harvesters:
| Model | Braud 405 | Braud 405-4 | Braud 405-6 |
| Years of production | 1963-67 | 1967 | 1967 |
| Engine manufacturer | Perkins | Perkins | Perkins |
| Engine model / type | P6 | A4.236 | A6.354 |
| Engine displacement (cm3) | 4730 | 3860 | 5800 |
| Number of cylinders / turbocharging | 6 | 4 | 6 |
| Engine rated power (hp) | 77 | 76 | 85 |
| Fuel tank capacity (l) | – | – | – |
| Type of drive transmission | mech | mech | mech |
| Number of gears (front + rear) | 3 | 3 | 3 |
| Driving speed min-max (km/h) | 1,7-18,0 | 1,7-18,0 | 1,7-18,0 |
Advertisement
| Cutting unit working width (cm) | 280 | 280 | 280 |
| Number of straw walkers | 4 | 4 | 4 |
| Total length (cm) | 803 | 803 | 803 |
| Total width (cm) | 320 | 320 | 320 |
| Width without cutting attachment (cm) | – | – | – |
| Height without cabin (cm) | 329 | 329 | 329 |
| Total height with cabin (cm) | – | – | – |
| Weight without cabin (kg) | 4330 | 4500 | – |
| Weight with cabin (kg) | – | – | – |
| Grain tank capacity (hl) | 21 | 21 | 21 |
| Front wheel size | 13.6/12-28 | 13.6/12-28 | 13.6/12-28 |
| Rear wheel size | 140-40 AT | 6.00-16 | 6.00-16 |
