Technical specifications of the agricultural tractor John Deere 6105R/6115R/6125R/6140R/6150R:
Advertisement
| Model | John Deere 6105R | John Deere 6115R | John Deere 6125R | John Deere 6140R | John Deere 6150R |
| Years of production | 2012-16 | 2012-16 | 2012-16 | 2012-16 | 2012-16 |
| Engine model / type | PVX | PVX | PVX | PVX | PVX |
| Number of cylinders / turbocharging | 4TI | 4TI | 4TI | 6TI | 6TI |
| Engine displacement (cm3) | 4530 | 4530 | 4530 | 6788 | 6788 |
| Piston dimension / stroke (mm) | 106,5×127 | 106,5×127 | 106,5×127 | 106,5×127 | 106,5×127 |
| Maximum engine power (hp) / rpm | 101(121)/2100 | 109(130)/2100 | 117(137)/2100 | 132(153)/2100 | 141(162)/2100 |
| Torque (Nm) / rpm | 492/1600 | 538/1600 | 585/1600 | 656/1600 | 702/1600 |
| Number of gears (front + rear) | 24+24 | 24+24 | 24+24 | 24+24 | 20+20 |
| Number of synchronized gears (front+rear) | 24+24 | 24+24 | 24+24 | 24+24 | 20+20 |
Advertisement
| Speed-Shift | – | – | – | – | – |
| Type of reverse | hydr | hydr | hydr | hydr | hydr |
| Driving speed (km/h) | 2,5-40 | 2,5-40 | 2,5-40 | 2,5-40 | 2,5-40 |
| Max Driving speed (km/h) | 40 (50) | 40 (50) | 40 (50) | 40 (50) | 40 (50) |
| Hydraulic pump capacity (L/min) | 80 (114) | 80 (114) | 80 (114) | 80 (114) | 80 (114) |
| 3-Point Hitch control | ehr | ehr | ehr | ehr | ehr |
| 3-point hitch max load (kg) | 4600 | 5300 | 6000 | 7200 | 8100 |
| PTO speed (rpm) | 540/750/1000 | 540/750/1000 | 540/750/1000 | 540/750/1000 | 540/750/1000 |
| Disc brake type (dry / wet) | – | – | – | – | – |
| Type of control of the braking system | – | – | – | – | – |
| Turning radius 2WD (m) | – | – | – | – | – |
| Turning radius 4WD (m) | 10,88 | 10,94 | 10,94 | 12,32 | 12,32 |
Advertisement
| Front wheel 2WD | – | – | – | – | – |
| Front wheel 4WD | 380/70R28 | 380/70R28 | 380/70R28 | 420/70R28 | 480/70R28 |
| Rear wheel 2WD | – | – | – | – | – |
| Rear wheel 4WD | 480/70R38 | 480/70R38 | 480/70R38 | 520/70R38 | 580/70R38 |
| 2WD total weight (kg) | – | – | – | – | – |
| 4WD total weight (kg) | 5440 | 5455 | 5470 | 6160 | 6195 |
| Total height with cabin (cm) | 280 | 280 | 280 | 290 | 290 |
| Total length (cm) | 454 | 454 | 454 | 493 | 493 |
| Total width (cm) | 258 | 258 | 258 | 277 | 277 |
| Fuel tank capacity (l) | 220 | 220 | 220 | 350 | 350 |
| Cabin sound level (dB) | 72 | 72 | 72 | 72 | 72 |
