Kubota M6040

Kubota M6040, M7040, M8540, M9540 – specs, opinions & photos

Looking for information about agricultural tractors Kubota M6040, M7040, M8540, M9540? In this article, you'll find answers to questions such as:

  • How much horsepower does each model have?
  • What is the engine capacity of these models?
  • What is the hydraulic pump output for each one?
  • What is the PTO speed of these tractors?

With a spec sheet presented in table form, comparing the tractors is quick and easy, and user reviews will help you make the right choice.

Table of contents:

Technical specifications of the agricultural tractors Kubota M6040, M7040, M8540, M9540:

Kubota M6040
Kubota M7040
Kubota M8540
Kubota M9540

Kubota M6040

  • Years of production: 2009-2014
  • Maximum engine power (HP) / at RPM: 64/2600
  • Number of gearbox speeds (forward + reverse): 15+15
  • Maximum speed (km/h): 40
  • Fuel tank capacity (L): 90

Kubota M7040

  • Years of production: 2009-2014
  • Maximum engine power (HP) / at RPM: 71/2600
  • Number of gearbox speeds (forward + reverse): 15+15
  • Maximum speed (km/h): 40
  • Fuel tank capacity (L): 90

Kubota M8540

  • Years of production: 2009-2014
  • Maximum engine power (HP) / at RPM: 85/2600
  • Number of gearbox speeds (forward + reverse): 18+18 (36+36)
  • Maximum speed (km/h): 40
  • Fuel tank capacity (L): 110

Kubota M9540

  • Years of production: 2009-2014
  • Maximum engine power (HP) / at RPM: 95/2600
  • Number of gearbox speeds (forward + reverse): 18+18 (36+36)
  • Maximum speed (km/h): 40
  • Fuel tank capacity (L): 110

For details and a comparison of the tractors, see the technical sheet below.

Advertisement


Technical Data Sheet for Kubota M6040, M7040, M8540, M9540 agricultural tractors:

Comparison of technical parameters of agricultural tractors
Model Kubota M6040 Kubota M7040 Kubota M8540 Kubota M9540
Years of production 2009-2014 2009-2014 2009-2014 2009-2014
Engine designation/type V3307-DI-TE3 V3307-DI-TE3 V3800-DI-TE3 V3800-DI-TE3
Number of cylinders / Turbo / Intercooler 4T 4T 4T 4T
Engine displacement (cm³) 3331 3331 3769 3769
Piston diameter / Stroke (mm) 94×120 94×120 100×120 100×120
Maximum engine power (HP) / at RPM 64/2600 71/2600 85/2600 95/2600
Torque (Nm) / at RPM 220/1600 252/1600 279/1600 308/1600
Number of gearbox speeds (forward + reverse) 15+15 15+15 18+18 (36+36) 18+18 (36+36)
Number of synchronized gears (forward + reverse) 15+15 15+15 18+18 (36+36) 18+18 (36+36)

Advertisement

Fast gearbox / Power shift – – – –
Reverser type hydr hydr hydr hydr
Speed range (km/h) 0,43-38 0,43-39 0,39-39 0,39-39
Maximum speed (km/h) 40 40 40 40
Hydraulic pump capacity (L/min) 61 61 64,3 64,3
Rear three-point hitch (TUV) control type mech mech mech mech
Maximum rear three-point hitch (TUV) lift capacity (kg) 2300 2300 4100 4100
Power take-off (PTO) speed (RPM) 540/750 540/750 540/750 540/750
Type of disc brake (dry/wet) – – – –
Brake system control type – – – –
Turning radius 2WD (m) – – – –
Turning radius 4WD (m) 6,8 6,8 7,6 7,6

Advertisement

Front tire size 2WD – – – –
Front tire size 4WD 320/70R20 320/85R20 360/70R24 360/70R24
Rear tire size 2WD – – – –
Rear tire size 4WD 420/70R28 420/85R28 480/70R34 480/70R34
Total weight 2WD (kg) – – – –
Total weight 4WD (kg) 2730 2730 3305 3305
Total height with cabin (cm) 255 255 265 265
Total length (cm) 368 368 396 396
Total width (cm) 211 211 225 225
Fuel tank capacity (L) 90 90 110 110
Cabin noise level (dB) – – – –

Advertisement
