MB Trac 65 70

MB-Trac 65/70 – specs, opinions & photos

Looking for information about agricultural tractors MB-Trac 65/70? In this article, you'll find answers to questions such as:

  • How much horsepower does each model have?
  • What is the engine capacity of these models?
  • What is the hydraulic pump output for each one?
  • What is the PTO speed of these tractors?

With a spec sheet presented in table form, comparing the tractors is quick and easy, and user reviews will help you make the right choice.


Technical specifications of the agricultural tractors MB-Trac 65/70:

MB-Trac 65/70

MB-Trac 65/70

  • Years of production: 1972-75
  • Maximum engine power (HP) / at RPM: 65/2400
  • Number of gearbox speeds (forward + reverse): 16+16
  • Maximum speed (km/h): 25
  • Fuel tank capacity (L): 120

For details and a comparison of the tractors, see the technical sheet below.

Advertisement

Technical Data Sheet for MB-Trac 65/70 agricultural tractors:

Comparison of technical parameters of agricultural tractors
Model MB-Trac 65/70
Years of production 1972-75
Engine designation/type OM 314
Number of cylinders / Turbo / Intercooler 4
Engine displacement (cm3) 3782
Piston diameter / Stroke (mm) 97×128
Maximum engine power (HP) / at RPM 65/2400
Torque (Nm) / at RPM 220/1600
Number of gearbox speeds (forward + reverse) 16+16
Number of synchronized gears (forward + reverse) 16+16

Advertisement

Fast gearbox / Power shift
Reverser type
Speed range (km/h) 1,2-25,0
Maximum speed (km/h) 25
Hydraulic pump capacity (L/min) 40
Rear three-point hitch (TUV) control type mech
Maximum rear three-point hitch (TUV) lift capacity (kg) 3000
Power take-off (PTO) speed (RPM) 540/1000
Type of disc brake (dry/wet) wet
Brake system control type hydr
Turning radius 2WD (m)
Turning radius 4WD (m) 10,6

Advertisement

Front tire size 2WD
Front tire size 4WD 14,9-24
Rear tire size 2WD
Rear tire size 4WD 14,9-24
Total weight 2WD (kg)
Total weight 4WD (kg) 3270
Total height with cabin (cm) 265
Total length (cm) 449
Wheelbase (cm) 240
Fuel tank capacity (L) 120
Cabin noise level (dB) 88

Fuel consumption and user reviews of tractors MB-Trac 65/70:

Add your opinion:

Easy work 0.0 l/h
Medium work 0.0 l/h
Hard work 0.0 l/h

Opinions posted:

No opinions.

Average fuel consumption:

Easy - l/h
Medium - l/h
Hard - l/h
