Renault Ceres 340

Renault Ceres 310, 320, 330, 340 – specs, opinions & photos

Looking for information about agricultural tractors Renault Ceres 310, 320, 330, 340? In this article, you'll find answers to questions such as:

  • How much horsepower does each model have?
  • What is the engine capacity of these models?
  • What is the hydraulic pump output for each one?
  • What is the PTO speed of these tractors?

With a spec sheet presented in table form, comparing the tractors is quick and easy, and user reviews will help you make the right choice.

Table of contents:

Technical specifications of the agricultural tractors Renault Ceres 310, 320, 330, 340:

Renault Ceres 310
Renault Ceres 320
Renault Ceres 330
Renault Ceres 340

Renault Ceres 310

  • Years of production: –
  • Maximum engine power (HP) / at RPM: 55/2350
  • Number of gearbox speeds (forward + reverse): 9+9/10+10
  • Maximum speed (km/h): 30/40
  • Fuel tank capacity (L): 115

Renault Ceres 320

  • Years of production: –
  • Maximum engine power (HP) / at RPM: 65/2350
  • Number of gearbox speeds (forward + reverse): 18+18/20+20
  • Maximum speed (km/h): 30/40
  • Fuel tank capacity (L): 115/145

Renault Ceres 330

  • Years of production: –
  • Maximum engine power (HP) / at RPM: 75/2350
  • Number of gearbox speeds (forward + reverse): 18+18/20+20
  • Maximum speed (km/h): 30/40
  • Fuel tank capacity (L): 115/145

Renault Ceres 340

  • Years of production: –
  • Maximum engine power (HP) / at RPM: 85/2350
  • Number of gearbox speeds (forward + reverse): 18+18/20+20
  • Maximum speed (km/h): 30/40
  • Fuel tank capacity (L): 115/145

For details and a comparison of the tractors, see the technical sheet below.

Advertisement


Technical Data Sheet for Renault Ceres 310, 320, 330, 340 tractors:

Comparison of technical parameters of agricultural tractors
Model Renault Ceres 310 Renault Ceres 320 Renault Ceres 330 Renault Ceres 340
Years of production – – – –
Engine designation/type DPS 3029 DRT DPS 4039 DRT DPS 4045 DRT DPS 4039 TRT
Number of cylinders / Turbo / Intercooler 3 4 4 4T
Engine displacement (cm³) 2940 3920 4530 3920
Piston diameter / Stroke (mm) 106,5×110 106,5×110 106,5×127 106,5×110
Maximum engine power (HP) / at RPM 55/2350 65/2350 75/2350 85/2350
Torque (Nm) / at RPM 205/1500 242/1500 284/1500 310/1500
Number of gearbox speeds (forward + reverse) 9+9/10+10 18+18/20+20 18+18/20+20 18+18/20+20
Number of synchronized gears (forward + reverse) 9+9/10+10 18+18/20+20 18+18/20+20 18+18/20+20

Advertisement

Fast gearbox / Power shift mech/hydr mech/hydr mech/hydr
Reverser type mech mech mech mech
Speed range (km/h) 1,8-39,0 1,8-39,0 1,8-39,0 1,8-39,0
Maximum speed (km/h) 30/40 30/40 30/40 30/40
Hydraulic pump capacity (L/min) 52 52 52 52
Rear three-point hitch (TUV) control type mech mech mech mech
Maximum rear three-point hitch (TUV) lift capacity (kg) 3750 3750 5200 5200
Power take-off (PTO) speed (RPM) 540/1000 540/1000 540/1000 540/1000
Type of disc brake (dry/wet) – – – –
Brake system control type hydr hydr hydr hydr
Turning radius 2WD (m) 7,6 7,7 8,3 8,3
Turning radius 4WD (m) 7,9 8,1 8,3 8,3

Advertisement

Front tire size 2WD 6,50-16 7,50-16 7,50-18 9,00-16
Front tire size 4WD 9,50-24 11,2-24 13,6R24 13,6R24
Rear tire size 2WD 14,9-28 16,9-28 16,9R34 16,9R34
Rear tire size 4WD 14,9-28 16,9-28 16,9R34 16,9R34
Total weight 2WD (kg) 2860 3160 3480 3455
Total weight 4WD (kg) 3140 3485 3675 3755
Total height with cabin (cm) 239 244 250 250
Total length (cm) 431 444 449 463
Total width (cm) 228 241/234 247/243 247/243
Fuel tank capacity (L) 115 115/145 115/145 115/145
Cabin noise level (dB) 74 74 – –
