Technical specifications of the agricultural tractor Renault Ceres 310/320/330/340:
Advertisement
| Model | Renault Ceres 310 | Renault Ceres 320 | Renault Ceres 330 | Renault Ceres 340 |
| Years of production | – | – | – | – |
| Engine model / type | DPS 3029 DRT | DPS 4039 DRT | DPS 4045 DRT | DPS 4039 TRT |
| Number of cylinders / turbocharging | 3 | 4 | 4 | 4T |
| Engine displacement (cm3) | 2940 | 3920 | 4530 | 3920 |
| Piston dimension / stroke (mm) | 106,5×110 | 106,5×110 | 106,5×127 | 106,5×110 |
| Maximum engine power (hp) / rpm | 55/2350 | 65/2350 | 75/2350 | 85/2350 |
| Torque (Nm) / rpm | 205/1500 | 242/1500 | 284/1500 | 310/1500 |
| Number of gears (front + rear) | 9+9/10+10 | 18+18/20+20 | 18+18/20+20 | 18+18/20+20 |
| Number of synchronized gears (front+rear) | 9+9/10+10 | 18+18/20+20 | 18+18/20+20 | 18+18/20+20 |
Advertisement
| Speed-Shift | mech/hydr | mech/hydr | mech/hydr | |
| Type of reverse | mech | mech | mech | mech |
| Driving speed (km/h) | 1,8-39,0 | 1,8-39,0 | 1,8-39,0 | 1,8-39,0 |
| Max Driving speed (km/h) | 30/40 | 30/40 | 30/40 | 30/40 |
| Hydraulic pump capacity (L/min) | 52 | 52 | 52 | 52 |
| 3-Point Hitch control | mech | mech | mech | mech |
| 3-point hitch max load (kg) | 3750 | 3750 | 5200 | 5200 |
| PTO speed (rpm) | 540/1000 | 540/1000 | 540/1000 | 540/1000 |
| Disc brake type (dry / wet) | – | – | – | – |
| Type of control of the braking system | hydr | hydr | hydr | hydr |
| Turning radius 2WD (m) | 7,6 | 7,7 | 8,3 | 8,3 |
| Turning radius 4WD (m) | 7,9 | 8,1 | 8,3 | 8,3 |
Advertisement
| Front wheel 2WD | 6,50-16 | 7,50-16 | 7,50-18 | 9,00-16 |
| Front wheel 4WD | 9,50-24 | 11,2-24 | 13,6R24 | 13,6R24 |
| Rear wheel 2WD | 14,9-28 | 16,9-28 | 16,9R34 | 16,9R34 |
| Rear wheel 4WD | 14,9-28 | 16,9-28 | 16,9R34 | 16,9R34 |
| 2WD total weight (kg) | 2860 | 3160 | 3480 | 3455 |
| 4WD total weight (kg) | 3140 | 3485 | 3675 | 3755 |
| Total height with cabin (cm) | 239 | 244 | 250 | 250 |
| Total length (cm) | 431 | 444 | 449 | 463 |
| Total width (cm) | 228 | 241/234 | 247/243 | 247/243 |
| Fuel tank capacity (l) | 115 | 115/145 | 115/145 | 115/145 |
| Cabin sound level (dB) | 74 | 74 | – | – |
