Technical Specifications of the Zetor Forterra HD 130 agricultural tractor:
Zetor Forterra HD 130 agricultural tractor was produced from 2012 to 2016. It features the 1506 engine, which has four cylinders with turbocharging and an intercooler (4TI). The engine displacement is 4156 cm³, with piston dimensions of 105 mm in diameter and 120 mm in stroke. The engine achieves a maximum power of 127 HP at 2200 revolutions per minute and a torque of 551 Nm at 1500 revolutions per minute. The gearbox has 30 forward gears and 30 reverse gears, all of which are synchronized, and the gearbox is equipped with three fast gears. The reverse is hydraulically controlled. The tractor can travel at speeds from 1.9 km/h to a maximum of 37.9 km/h, with a maximum driving speed of 40 km/h. The hydraulic pump output is 85 liters per minute, with the option to increase to 120 liters per minute. The rear lift is electronically controlled (EHR) and has a maximum lift capacity of 8500 kg. The power take-off (PTO) operates at 540, 750, 1000, or 1250 revolutions per minute. The turning radius for the 4WD version is 9.6 meters. The front tire size for the 4WD version is 480/65R24, and the rear tire size is 600/65R38. The total weight of the 4WD version is 4820 kg. The tractor’s dimensions are: height with cab 284 cm, length 477 cm, and width 272 cm. The fuel tank capacity is 220 liters. The noise level in the cab is 76 dB.
Advertisement
Technical Data Sheet for Zetor Forterra HD 130, 140, 150 agricultural tractors:
| Model | Zetor Forterra HD 130 | Zetor Forterra HD 140 | Zetor Forterra HD 150 |
| Years of production | 2012-16 | 2012-16 | 2012-16 |
| Engine model / type | 1506 | 1606 | 1716 |
| Number of cylinders / turbocharging | 4TI | 4TI | 4TI |
| Engine displacement (cm3) | 4156 | 4156 | 4156 |
| Piston dimension / stroke (mm) | 105×120 | 105×120 | 105×120 |
| Maximum engine power (hp) / rpm | 127/2200 | 136/2200 | 147/2200 |
| Torque (Nm) / rpm | 551/1500 | 581/1500 | 589/1500 |
| Number of gears (front + rear) | 30+30 | 30+30 | 30+30 |
| Number of synchronized gears (front+rear) | 30+30 | 30+30 | 30+30 |
Advertisement
| Speed-Shift | 3 | 3 | 3 |
| Type of reverse | hydr | hydr | hydr |
| Driving speed (km/h) | 1,9-37,9 | 1,9-37,9 | 1,9-37,9 |
| Max Driving speed (km/h) | 40 | 40 | 40 |
| Hydraulic pump capacity (L/min) | 85 (120) | 85 (120) | 85 (120) |
| 3-Point Hitch control | ehr | ehr | ehr |
| 3-point hitch max load (kg) | 8500 | 8500 | 8500 |
| PTO speed (rpm) | 540/750/1000/1250 | 540/750/1000/1250 | 540/750/1000/1250 |
| Disc brake type (dry / wet) | – | – | – |
| Type of control of the braking system | – | – | – |
| Turning radius 2WD (m) | – | – | – |
| Turning radius 4WD (m) | 9,6 | 9,6 | 9,6 |
Advertisement
| Front wheel 2WD | – | – | – |
| Front wheel 4WD | 480/65R24 | 480/65R24 | 480/65R24 |
| Rear wheel 2WD | – | – | – |
| Rear wheel 4WD | 600/65R38 | 600/65R38 | 600/65R38 |
| 2WD total weight (kg) | – | – | – |
| 4WD total weight (kg) | 4820 | 4820 | 4820 |
| Total height with cabin (cm) | 284 | 284 | 284 |
| Total length (cm) | 477 | 477 | 477 |
| Total width (cm) | 272 | 272 | 272 |
| Fuel tank capacity (l) | 220 | 220 | 220 |
| Cabin sound level (dB) | 76 | 76 | 76 |
