Zetor Major 3320/3340/5320/5340/6320/6340/7320/7340 Specs

Full technical specification of agricultural tractor Zetor Major 3320/3340/5320/5340/6320/6340/7320/7340 :

Model Zetor Major 3320/3340 Zetor Major 5320/5340 Zetor Major 6320/6340 Zetor Major 7320/7340
Years of production N/A N/A N/A N/A
Engine model / type Z5201 Z7201 Z7701 Z7301
Number of cylinders / turbocharging 3 4 4 4T
Engine displacement (cm3) 2696 3595 3922 3922
Piston dimension / stroke (mm) 102×110 102×110 102×120 102×120
Maximum engine power (hp) / rpm 45/2200 63/2200 68/2200 78/2200
Torque (Nm) / rpm N/A N/A N/A N/A
Number of gears (front + rear) N/A N/A N/A N/A
Number of synchronized gears (front+rear) 10+2 10+2 10+2 10+2
Speed-Shift 8 8 8 8
Type of reverse N/A N/A N/A N/A
Driving speed (km/h) 2,0-35,8 2,0-35,8 2,0-35,8 2,0-35,8
Max Driving speed (km/h) 30/36 30/36 30/36 30/36
Hydraulic pump capacity (L/min) 40 40 40 40
3-Point Hitch control mech mech mech mech
3-point hitch max load (kg) 1900/2700 2700/3450 2700/3450 2700/3450
PTO speed (rpm) 540 540 540 540
Disc brake type (dry / wet) N/A N/A N/A N/A
Type of control of the braking system N/A N/A N/A N/A
Turning radius 2WD (m) 7,4 7,6 7,6 7,6
Turning radius 4WD (m) 8 8,9 8,9 8,9
Front wheel 2WD 6,50-16 7,50-20 7,50-20 7,50-20
Front wheel 4WD 9,5-24 11,2-24 11,2-24 12,4-24
Rear wheel 2WD 14,9-28 16,9-30 16,9-30 16,9-34
Rear wheel 4WD 14,9-28 16,9-30 16,9-30 16,9-34
2WD total weight (kg) 2680 2890 2895 2895
4WD total weight (kg) 3080 3345 3365 3440
Total height with cabin (cm) 264 264 264 269
Total length (cm) 363 377 377 377
Total width (cm) 212/214 226/222 226/222 226/222
Fuel tank capacity (l) 80/85 80/85 80/85 80/85
Cabin sound level (dB) N/A N/A N/A N/A
