Technical specifications of the combine harvesters Sampo 2035, 2045, 2065, 2085 TS:
Sampo 2035
- Years of production: –
- Rated engine power (HP): 100
- Fuel tank capacity (L): 200
- Cutting unit/header working width (cm): 310
- Grain tank capacity (hl): 33
Sampo 2045
- Years of production: –
- Rated engine power (HP): 115
- Fuel tank capacity (L): 200
- Cutting unit/header working width (cm): 345
- Grain tank capacity (hl): 37
Sampo 2065
- Years of production: –
- Rated engine power (HP): 150
- Fuel tank capacity (L): 300/350
- Cutting unit/header working width (cm): 420
- Grain tank capacity (hl): 42
Sampo 2085 TS
- Years of production: –
- Rated engine power (HP): 175
- Fuel tank capacity (L): 300/350
- Cutting unit/header working width (cm): 450
- Grain tank capacity (hl): 46/52
For details and a comparison of the combines, see the technical sheet below.
Advertisement
Data sheet for Sampo 2045, 2035, 2065, 2085 TS combine harvesters with Sisu engine:
| Model | Sampo 2035 | Sampo 2045 | Sampo 2065 | Sampo 2085 TS |
|---|---|---|---|---|
| Years of production | – | – | – | – |
| Engine manufacturer | SisuDiesel | SisuDiesel | SisuDiesel | SisuDiesel |
| Engine designation/type | 44 DT | 44 ET | 66 ET | 66 ET |
| Engine displacement (cm³) | 4400 | 4400 | 6600 | 6600 |
| Number of cylinders / turbocharging | 4 T | 4 T | 6 T | 6 T |
| Rated engine power (HP) | 100 | 115 | 150 | 175 |
| Fuel tank capacity (L) | 200 | 200 | 300/350 | 300/350 |
| Type of transmission system | hydr | hydr | hydr | hydr |
| Number of gearbox speeds | 3 | 3 | 3 | 3 |
| Minimum-maximum driving speed (km/h) | 0-25 | 0-25 | 0-26 | 0-26 |
Advertisement
| Cutting unit/header working width (cm) | 310 | 345 | 420 | 450 |
|---|---|---|---|---|
| Number of straw walkers | 4 | 4 | 5 | 5 |
| Total length (cm) | 825 | 868 | 850 | 850 |
| Total width (cm) | 343 | 378 | 453 | 453 |
| Width without cutting unit/header (cm) | 283 | 288 | 324 | 324 |
| Height without cab (cm) | – | – | – | – |
| Total height with cab (cm) | 350 | 350/365 | 350/365 | 365 |
| Weight without cab (kg) | – | – | – | – |
| Weight with cab (kg) | 6000 | 6800 | 7700 | 8600 |
| Grain tank capacity (hl) | 33 | 37 | 42 | 46/52 |
| Front wheel size | 18,4R34 | 520/70R34 | 600/65R34 | 600/65R34 |
| Rear wheel size | 360/70R20 | 360/70R20 | 420/65R20 | 420/65R20 |
