Landini Globus 50, 60, 70, 55, 65, 75, 80 ⚙️ Specs

Technical Specifications of the Landini Globus 50 Agricultural Tractor:

Landini Globus 50 was produced from 1996 to 1999, equipped with a three-cylinder Perkins engine with a displacement of 2,700 cm³ and piston dimensions of 95 × 127 mm. The engine delivers 47 HP at 2,250 RPM and a peak torque of 172 Nm at 1,200 RPM. The tractor features a hydraulic quick-shift transmission and a mechanical shuttle, reaching speeds from 1.9 to 39.1 km/h, with a maximum speed of 30 or 40 km/h. The hydraulic pump has a flow rate of 40 l/min, while the mechanically controlled rear hitch provides a maximum lift capacity of 2,100 kg, expandable to 3,400 kg. The PTO operates at speeds of 540 and 750 RPM. The turning radius in the 4WD version is 6.18 m. The tire sizes for the 2WD version are 7.50-16 (front) and 14.9R28 (rear), while for the 4WD version, they are 12.4R20 (front) and 14.9R28 (rear). The total weight is 2,350 kg for the 2WD version and 2,470 kg for the 4WD version. The tractor’s dimensions are 365/361 cm in length, 207/201 cm in width, and 236/243 cm in height, including the cab. The fuel tank capacity is 53 liters, and the in-cab noise level is 82 dB.

Advertisement

Technical Data Sheet for Landini Globus 50, 60, 70, 55, 65, 75, 80 Tractors:

Model Landini Globus 50 Landini Globus 60 Landini Globus 70 Landini Globus 55 Landini Globus 65 Landini Globus 75 Landini Globus 80
Years of production 1996-99 1996-99 1996-99 1999-2004 1999-2004 1999-2001
Engine model / type Perkins Perkins 704-30 Perkins Perkins 903-27 Perkins Perkins 1004-42 Perkins
Number of cylinders / turbocharging 3 4 4 3 4 4 4
Engine displacement (cm3) 2700 3000 3000 2700 3990 4230 4230
Piston dimension / stroke (mm) 95×127 97×100 97×100 95×127 100×127 103×127 103×127
Maximum engine power (hp) / rpm 47/2250 56/2600 66/2600 54/2250 67/2200 73/2200 78/2200
Torque (Nm) / rpm 172/1200 190/1600 220/1600 193/1200 263/1300 282/1400 284/1400
Number of gears (front + rear)
Number of synchronized gears (front+rear)

Advertisement

Speed-Shift hydr hydr hydr hydr hydr hydr hydr
Type of reverse mech mech mech mech mech mech mech
Driving speed (km/h) 1,9-39,1 1,9-39,1 1,9-39,1 0,2-39,1 0,2-39,1 0,2-39,1 0,2-39,1
Max Driving speed (km/h) 30/40 30/40 30/40 30/40 30/40 30/40 30/40
Hydraulic pump capacity (L/min) 40 40/35/39 40/35 31/39 54 54 54
3-Point Hitch control mech mech mech mech mech mech mech
3-point hitch max load (kg) 2100 (3400) 2100 (3400) 2100 (3400) 2100 (3400) 2100 (3400) 2100 (3400) 3400
PTO speed (rpm) 540/750 540/750 540/750 540/750 540/750 540/750 540/750
Disc brake type (dry / wet)
Type of control of the braking system
Turning radius 2WD (m)
Turning radius 4WD (m) 6,18 6,18 6,18 6,18 6,18 6,18 6,18

Advertisement

Front wheel 2WD 7.50-16 7.50-16 7.50-16 7.50-16 7.50-16 7.50-16 7.50-16
Front wheel 4WD 12.4R20 12.4R20 12.4R20 320/70R20 360/70R20 320/70R24 320/70R24
Rear wheel 2WD 14.9R28 14.9R28 14.9R30 14.9R28 14.9R28 14.9R30 14.9R30
Rear wheel 4WD 14.9R28 14.9R30 14.9R30 420/70R28 420/70R30 480/70R30 480/70R30
2WD total weight (kg) 2350 2350 2350 2350
4WD total weight (kg) 2470 2630 2700 2570 3050 3100 3100
Total height with cabin (cm) 236/243 236/245 236/245 236/243 236/251 236/251 236/251
Total length (cm) 365/361 365/361 365/361 365/361 365/371 365/371 365/371
Total width (cm) 207/201 207/201 207/201 207/201 215 215 215
Fuel tank capacity (l) 53 53 53 53 (86) 67 (100) 67 (100) 67 (100)
Cabin sound level (dB) 82 82 82 82 82 82 82
