Technical Specifications of the Fendt 5270 C Combine Harvester:
Fendt 5270 C Combine Harvester is equipped with a SisuDiesel 74 ETA engine with a displacement of 7400 cm³, generating 275 HP. The engine has six cylinders and turbocharging. The combine has a hydrostatic transmission with four speeds. The cutting unit has a working width of 540 cm, and inside the combine, there are five straw walkers. The dimensions of the combine are 891 cm in length, 363 cm in width without the cutting unit, and 400 cm in height with the cab. The grain tank capacity is 90 hectoliters. The front wheels are size 800/65R32, and the rear wheels are size 460/70R24. The fuel tank capacity is 600 liters.
Advertisement
Data sheet for Fendt 5270 C, 6300 C combine harvesters:
| Model | Fendt 5270 C | Fendt 6300 C |
| Years of production | – | – |
| Engine manufacturer | SisuDiesel | SisuDiesel |
| Engine model / type | 74 ETA | 84 ETA |
| Engine displacement (cm3) | 7400 | 8400 |
| Number of cylinders / turbocharging | 6T | 6T |
| Engine rated power (hp) | 275 | 305(330) |
| Fuel tank capacity (l) | 600 | 600 |
| Type of drive transmission | hydr | hydr |
| Number of gears (front + rear) | 4 | 4 |
| Driving speed min-max (km/h) | – | – |
Advertisement
| Cutting unit working width (cm) | 540 | 600 |
| Number of straw walkers | 5 | 6 |
| Total length (cm) | 891 | 891 |
| Total width (cm) | – | – |
| Width without cutting attachment (cm) | 363 | 388 |
| Height without cabin (cm) | – | – |
| Total height with cabin (cm) | 400 | 400 |
| Weight without cabin (kg) | – | – |
| Weight with cabin (kg) | – | – |
| Grain tank capacity (hl) | 90 | 90 |
| Front wheel size | 800/65R32 | 800/65R32 |
| Rear wheel size | 460/70R24 | 460/70R24 |
