Fendt 5275 C, 6335 C ⚙️ Specs

Technical specifications of the Fendt 5275 C Combine Harvester:

Fendt 5275 C Combine Harvester has been produced since 2015. It is equipped with an Agco Power 74 AWF engine with a displacement of 7368 cm³, generating 276 HP (306 HP with additional boost). The engine has six cylinders, turbocharging, and an intercooler. The combine has a hydrostatic transmission with four speeds, allowing a driving speed from 0 to 25 km/h. The cutting unit has a working width of 540 cm, and inside the combine, there are five straw walkers. The dimensions of the combine are 904 cm in length, 365 cm in width without the cutting unit, and 400 cm in height with the cab. The grain tank capacity is 90 hectoliters (86 hectoliters standard). The front wheels are size 800/65R32, and the rear wheels are size 460/70R24. The fuel tank capacity is 620 liters with the addition of AB80.

Advertisement

Data sheet for Fendt 6335 C, 5275 C combine harvesters:

Model Fendt 5275 C Fendt 6335 C
Years of production 2015- 2015-
Engine manufacturer Agco Power Agco Power
Engine model / type 74 AWF 84 AWF
Engine displacement (cm3) 7368 8400
Number of cylinders / turbocharging 6TI 6TI
Engine rated power (hp) 276(306) 335(360)
Fuel tank capacity (l) 620+AB80 620+AB80
Type of drive transmission hydr hydr
Number of gears (front + rear) 4 4
Driving speed min-max (km/h) 0-25 0-25

Advertisement

Cutting unit working width (cm) 540 600
Number of straw walkers 5 6
Total length (cm) 904 904
Total width (cm)
Width without cutting attachment (cm) 365 390
Height without cabin (cm)
Total height with cabin (cm) 400 400
Weight without cabin (kg)
Weight with cabin (kg)
Grain tank capacity (hl) 90 (86) 90 (86)
Front wheel size 800/65R32 800/65R32
Rear wheel size 460/70R24 460/70R24
