New Holland T6010, T6020, T6030, T6040, T6050, T6060, T6070, T6080, T6090 – specs, opinions & photos

Looking for information about agricultural tractors New Holland T6010, T6020, T6030, T6040, T6050, T6060, T6070, T6080, T6090? In this article, you'll find answers to questions such as:

  • How much horsepower does each model have?
  • What is the engine capacity of these models?
  • What is the hydraulic pump output for each one?
  • What is the PTO speed of these tractors?

With a spec sheet presented in table form, comparing the tractors is quick and easy, and user reviews will help you make the right choice.

Table of contents:

Technical specifications of the agricultural tractors New Holland T6010, T6020, T6030, T6040, T6050, T6060, T6070, T6080, T6090:

New Holland T6010
New Holland T6020
New Holland T6030
New Holland T6040
New Holland T6050
New Holland T6060
New Holland T6070
New Holland T6080
New Holland T6090

New Holland T6010

  • Years of production: –
  • Maximum engine power (HP) / at RPM: 101/2200
  • Number of gearbox speeds (forward + reverse): 24+24/16+16
  • Maximum speed (km/h): –
  • Fuel tank capacity (L): 176 (SS 152)

New Holland T6020

  • Years of production: –
  • Maximum engine power (HP) / at RPM: 112/2200
  • Number of gearbox speeds (forward + reverse): 24+24/16+16
  • Maximum speed (km/h): –
  • Fuel tank capacity (L): 176 (SS 152)

New Holland T6030

  • Years of production: –
  • Maximum engine power (HP) / at RPM: 117/2200
  • Number of gearbox speeds (forward + reverse): 24+24/16+16
  • Maximum speed (km/h): –
  • Fuel tank capacity (L): 250 (SS 230)

New Holland T6040

  • Years of production: –
  • Maximum engine power (HP) / at RPM: 122(141)/2200
  • Number of gearbox speeds (forward + reverse): 16+16
  • Maximum speed (km/h): 40 (48)
  • Fuel tank capacity (L): 176 (SS 152)

New Holland T6050

  • Years of production: –
  • Maximum engine power (HP) / at RPM: 125(159)/2200
  • Number of gearbox speeds (forward + reverse): 16+16
  • Maximum speed (km/h): 40 (48)
  • Fuel tank capacity (L): 250 (SS 230)

New Holland T6060

  • Years of production: –
  • Maximum engine power (HP) / at RPM: 132(141)/2200
  • Number of gearbox speeds (forward + reverse): 16+16
  • Maximum speed (km/h): 40 (48)
  • Fuel tank capacity (L): 176 (SS 152)

New Holland T6070

  • Years of production: –
  • Maximum engine power (HP) / at RPM: 141(169)/2200
  • Number of gearbox speeds (forward + reverse): 16+16
  • Maximum speed (km/h): 40 (48)
  • Fuel tank capacity (L): 250 (SS 230)

New Holland T6080

  • Years of production: –
  • Maximum engine power (HP) / at RPM: 155(167)/2200
  • Number of gearbox speeds (forward + reverse): 18+6
  • Maximum speed (km/h): 40 (51)
  • Fuel tank capacity (L): 300

New Holland T6090

  • Years of production: –
  • Maximum engine power (HP) / at RPM: 165(190)/2200
  • Number of gearbox speeds (forward + reverse): 18+6
  • Maximum speed (km/h): 40 (51)
  • Fuel tank capacity (L): 300

For details and a comparison of the tractors, see the technical sheet below.

Advertisement


Technical Data Sheet for New Holland T6010, T6020, T6030, T6040, T6050, T6060, T6070, T6080, T6090 tractors:

Comparison of technical parameters of agricultural tractors
Model New Holland T6010 New Holland T6020 New Holland T6030 New Holland T6040 New Holland T6050 New Holland T6060 New Holland T6070 New Holland T6080 New Holland T6090
Years of production – – – – – – – – –
Engine designation/type NEF NEF NEF NEF NEF NEF NEF NEF NEF
Number of cylinders / Turbo / Intercooler 4TI 4TI 6TI 4TI 6TI 4TI 6TI 6TI 6TI
Engine displacement (cm³) 4485 4485 6728 4485 6728 4485 6728 6728 6728
Piston diameter / Stroke (mm) 104×132 104×132 104×132 104×132 104×132 104×132 104×132 104×132 104×132
Maximum engine power (HP) / at RPM 101/2200 112/2200 117/2200 122(141)/2200 125(159)/2200 132(141)/2200 141(169)/2200 155(167)/2200 165(190)/2200
Torque (Nm) / at RPM 400/1400 455/1400 516/1400 563/1400 593/1400 594/1400 613/1400 690/1400 710/1400
Number of gearbox speeds (forward + reverse) 24+24/16+16 24+24/16+16 24+24/16+16 16+16 16+16 16+16 16+16 18+6 18+6
Number of synchronized gears (forward + reverse) – – – 16+16 16+16 16+16 16+16 18+6 18+6

Advertisement

Fast gearbox / Power shift – – – 4 4 4 4 – –
Reverser type hydr hydr hydr hydr hydr hydr hydr hydr hydr
Speed range (km/h) 40 (48) 40 (48) 40 (48) 2,4-39,0 2,4-39,0 2,4-39,0 2,4-39,0 2,2-38 2,2-38
Maximum speed (km/h) – – – 40 (48) 40 (48) 40 (48) 40 (48) 40 (51) 40 (51)
Hydraulic pump capacity (L/min) 113 113 113 113 113 113 113 113 113
Rear three-point hitch (TUV) control type ehr ehr ehr ehr ehr ehr ehr ehr ehr
Maximum rear three-point hitch (TUV) lift capacity (kg) 7864 7864 7864 7864 7864 7864 7864 8257 8257
Power take-off (PTO) speed (RPM) 540/750/1000 540/750/1000 540/750/1000 540/750/1000 540/750/1000 540/750/1000 540/750/1000 540/750/1000 540/750/1000
Type of disc brake (dry/wet) – – – – – – – – –
Brake system control type – – – – – – – – –
Turning radius 2WD (m) – – – – – – – – –
Turning radius 4WD (m) – – – – – – – – –

Advertisement

Front tire size 2WD – – – – – – – – –
Front tire size 4WD 13.6R28 14.9R28 14.9R28 14.9R28 14.9R28 14.9R28 14.9R28 16.9R28 16.9R28
Rear tire size 2WD – – – – – – – – –
Rear tire size 4WD 16.9R38 18.4R38 18.4R38 18.4R38 18.4R38 18.4R38 18.4R38 20.8R38 20.8R38
Total weight 2WD (kg) – – – – – – – – –
Total weight 4WD (kg) 5060 (SS 5340) 5230 (SS 5610) 5330 (SS 5610) 5250 (SS 5430) 5330 (SS 5610) 5250 (SS 5430) 5330 (SS 5610) 6300 (6600) 6300 (6600)
Total height with cabin (cm) 280 (290) 284 (294) 284 (294) 292 298 292 298 305 305
Total length (cm) 429 429 453 429 453 429 453 482 482
Total width (cm) 241 (SS 252) 241 (SS 252) 265 (SS 276) 241 (SS 252) 265 (SS 276) 241 (SS 252) 265 (SS 276) 273 (SS 288) 273 (SS 288)
Fuel tank capacity (L) 176 (SS 152) 176 (SS 152) 250 (SS 230) 176 (SS 152) 250 (SS 230) 176 (SS 152) 250 (SS 230) 300 300
Cabin noise level (dB) 70 70 73 71 72 71 72 72 72

Advertisement

Fuel consumption and user reviews of tractors New Holland T6010, T6020, T6030, T6040, T6050, T6060, T6070, T6080, T6090:

Add your opinion:

Easy work 0.0 l/h
Medium work 0.0 l/h
Hard work 0.0 l/h

Opinions posted:

No opinions.

Average fuel consumption:

Easy - l/h
Medium - l/h
Hard - l/h
