Technical specifications of the agricultural tractor Steyr Plus 70 / 870/980/90 / 1090/1100/1200:
Advertisement
| Model | Steyr Plus 70 / 870 | Steyr Plus 980 | Steyr Plus 90 / 1090 | Steyr Plus 1100 | Steyr Plus 1200 |
| Years of production | 1968-75 | 1974-77 | 1968-74 | 1971-77 | 1972-75 |
| Engine model / type | WD 410t | WD 412.40 | WD 610t | WD 610.40 | WD 610.43 |
| Number of cylinders / turbocharging | 4 | 4 | 6 | 6 | 6 |
| Engine displacement (cm3) | 3983 | 4394 | 5976 | 5976 | 5976 |
| Piston dimension / stroke (mm) | 105×115 | 108×120 | 105×115 | 105×115 | 105×115 |
| Maximum engine power (hp) / rpm | 70/2400 | 80/2200 | 90/2200 | 100/2100 | 115/2200 |
| Torque (Nm) / rpm | 250/1400 | 294/1600 | 353/1200 | 363/1500 | 382/1600 |
| Number of gears (front + rear) | 12+6 | 12+6 | 12+6 | 12+6 | 12+6 |
| Number of synchronized gears (front+rear) | 12+6 | 12+6 | 12+6 | 12+6 | 12+6 |
Advertisement
| Speed-Shift | – | – | – | – | – |
| Type of reverse | – | – | – | – | – |
| Driving speed (km/h) | 2,1-24,9 | 2,4-29,4 | 1,9-23,2 | 2,3-27,4 | 2,4-24,5 |
| Max Driving speed (km/h) | – | – | – | – | – |
| Hydraulic pump capacity (L/min) | 32 | 32 | 32 | 35,5 | 35,5 |
| 3-Point Hitch control | mech | mech | mech | mech | mech |
| 3-point hitch max load (kg) | 2900/3800 | 3800 | 2900/3800 | 3800 | 3800 |
| PTO speed (rpm) | 540/1000 | 540/1000 | 540/1000 | 540/1000 | 540/1000 |
| Disc brake type (dry / wet) | – | – | – | – | – |
| Type of control of the braking system | – | – | – | – | – |
| Turning radius 2WD (m) | 8,8 | 8,2 | 9,6 | 8,75 | 9 |
| Turning radius 4WD (m) | 10 | 10 | 12,2 | 13,3/12,2 | 13,3/12,2 |
Advertisement
| Front wheel 2WD | – | – | – | – | – |
| Front wheel 4WD | – | – | – | – | – |
| Rear wheel 2WD | – | – | – | – | – |
| Rear wheel 4WD | – | – | – | – | – |
| 2WD total weight (kg) | 3240 | 3445 | 3650 | 3805 | 4505 |
| 4WD total weight (kg) | 3570 | 3785 | 3960 | 4280 | 4980 |
| Total height with cabin (cm) | 237 | 262 | 243 | 249 | 253 |
| Total length (cm) | 387 | 389 | 419 | 419/432 | 419/440 |
| Total width (cm) | 228/234 | 228/234 | 253/259 | 253/259 | 253/259 |
| Fuel tank capacity (l) | 108 | 108 | 118 | 118 | 118 |
| Cabin sound level (dB) | – | – | – | – | – |
