Technical specifications of the agricultural tractor Deutz Fahr Agrotron 108/118/128/120/130/150:
Advertisement
| Model | Deutz Fahr Agrotron 108 | Deutz Fahr Agrotron 118 | Deutz Fahr Agrotron 128 | Deutz Fahr Agrotron 120 | Deutz Fahr Agrotron 130 | Deutz Fahr Agrotron 150 |
| Years of production | – | – | – | – | – | – |
| Engine model / type | BF6M2012C | BF6M2012C | BF6M2012C | BF6M2012C | BF6M2012C | BF6M2012C |
| Number of cylinders / turbocharging | 6TI | 6TI | 6TI | 6TI | 6TI | 6TI |
| Engine displacement (cm3) | 6057 | 6057 | 6057 | 6057 | 6057 | 6057 |
| Piston dimension / stroke (mm) | 101×126 | 101×126 | 101×126 | 101×126 | 101×126 | 101×126 |
| Maximum engine power (hp) / rpm | 109/2300 | 120/2300 | 126/2300 | 109/2300 | 120/2300 | 145/2300 |
| Torque (Nm) / rpm | 476/1200 | 512/1100 | 552/1200 | 476/1200 | 512/1100 | 590/1100 |
| Number of gears (front + rear) | 24+24 | 24+24 | 24+24 | 24+24 | 24+24 | 24+24 |
| Number of synchronized gears (front+rear) | 24+24 | 24+24 | 24+24 | 24+24 | 24+24 | 24+24 |
Advertisement
| Speed-Shift | 4 | 4 | 4 | 4 | 4 | 4 |
| Type of reverse | hydr | hydr | hydr | hydr | hydr | hydr |
| Driving speed (km/h) | 3,1-40/50 | 3,1-40/50 | 3,1-40/50 | 3,1-40/50 | 3,1-40/50 | 3,2-40/50 |
| Max Driving speed (km/h) | 40/50 | 40/50 | 40/50 | 40/50 | 40/50 | 40/50 |
| Hydraulic pump capacity (L/min) | 83 (120) | 83 (120) | 83 (120) | 83 (120) | 83 (120) | 83 (120) |
| 3-Point Hitch control | ehr | ehr | ehr | ehr | ehr | ehr |
| 3-point hitch max load (kg) | 6220 (9200) | 6220 (9200) | 6220 (9200) | 6220 (9200) | 6220 (9200) | 9200 |
| PTO speed (rpm) | 540/750 | 540/750 | 540/750 | 540/750 | 540/750 | 540/750 |
| Disc brake type (dry / wet) | – | – | – | – | – | – |
| Type of control of the braking system | – | – | – | – | – | – |
| Turning radius 2WD (m) | – | – | – | – | – | – |
| Turning radius 4WD (m) | 9,9 | 9,9 | 9,9 | 9,9 | 9,9 | 10,26 |
Advertisement
| Front wheel 2WD | – | – | – | – | – | – |
| Front wheel 4WD | 16.9R24 | 16.9R24 | 16.9R24 | 16.9R24 | 16.9R24 | 480/70R28 |
| Rear wheel 2WD | – | – | – | – | – | – |
| Rear wheel 4WD | 18.4R38 | 18.4R38 | 18.4R38 | 18.4R38 | 18.4R38 | 580/70R28 |
| 2WD total weight (kg) | – | – | – | – | – | – |
| 4WD total weight (kg) | 5450 | 5450 | 5450 | 5460 | 5460 | 5610 |
| Total height with cabin (cm) | 288 | 288 | 288 | 288 | 288 | 299 |
| Total length (cm) | 459 | 459 | 459 | 459 | 459 | 459 |
| Total width (cm) | 265 | 265 | 265 | 265 | 265 | 265 |
| Fuel tank capacity (l) | 270 | 270 | 270 | 270 | 270 | 270 |
| Cabin sound level (dB) | 73 | 73 | 73 | 73 | 73 | 73 |
